• PATLITE RFT LED Rotating Beacon with Audible Alarm, Φ100 mm
1 1

PATLITE RFT LED Rotating Beacon with Audible Alarm, Φ100 mm

PATLITE RFT LED Rotating Beacon with Audible Alarm, Φ100 mm

Φ100 mm LED rotating-pattern beacon on a housing with a 90 dB electronic alarm offering 32 sounds. 32 alarm sounds from sound charts Type A, C, D or E; 8/32 bit/binary inputs. 90 dB, 115 flashes/min.

Key features

  • IP54

Specifications

Size Φ100 mm (115 mm square housing)
Supported Transistors NPN
Volume Control Rotating knob
Use Indoor/Outdoor
Ambient Temperature -20 to +50°C
Ingress Protection IP54
Approvals CE (DC type), UKCA (DC type), RoHS10
RFT-24A-R Rated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-Y Rated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-G Rated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-B Rated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-R Rated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-Y Rated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-G Rated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-B Rated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-R Rated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-Y Rated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-G Rated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-B Rated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-R Rated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-Y Rated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-G Rated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-B Rated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-100A-R Rated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-Y Rated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-G Rated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-B Rated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-R Rated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-Y Rated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-G Rated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-B Rated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-R Rated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-Y Rated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-G Rated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-B Rated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-R Rated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-Y Rated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-G Rated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-B Rated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-R Rated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-Y Rated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-G Rated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-B Rated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-R Rated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-Y Rated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-G Rated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-B Rated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-R Rated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-Y Rated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-G Rated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-B Rated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-R Rated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-Y Rated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-G Rated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-B Rated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
Rotating BeaconsPATLITE
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

PATLITE RFT LED Rotating Beacon with Audible Alarm, Φ100 mm

Brand PATLITE·Rotating Beacons

Available part numbers (48)

RFT-24A-R, RFT-24A-Y, RFT-24A-G, RFT-24A-B, RFT-24C-R, RFT-24C-Y, RFT-24C-G, RFT-24C-B, RFT-24D-R, RFT-24D-Y + 38 more — see full table ↓

How to order

Send the PATLITE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
RFT-24A-RRated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-YRated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-GRated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24A-BRated Voltage: 24V DC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-RRated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-YRated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-GRated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24C-BRated Voltage: 24V DC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-RRated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-YRated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-GRated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24D-BRated Voltage: 24V DC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-RRated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-YRated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-GRated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 12 W | Mass: 1.0 kg
RFT-24E-BRated Voltage: 24V DC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 12 W | Mass: 1.0 kg
RFT-100A-RRated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-YRated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-GRated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100A-BRated Voltage: 100V AC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-RRated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-YRated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-GRated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100C-BRated Voltage: 100V AC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-RRated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-YRated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-GRated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100D-BRated Voltage: 100V AC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-RRated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-YRated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-GRated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-100E-BRated Voltage: 100V AC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-RRated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-YRated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-GRated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220A-BRated Voltage: 220V AC | Alarm Type: Type A | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-RRated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-YRated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-GRated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220C-BRated Voltage: 220V AC | Alarm Type: Type C | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-RRated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-YRated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-GRated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220D-BRated Voltage: 220V AC | Alarm Type: Type D | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-RRated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Red | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-YRated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Amber | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-GRated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Green | Power Consumption: 13 W | Mass: 1.2 kg
RFT-220E-BRated Voltage: 220V AC | Alarm Type: Type E | Luminous Color: Blue | Power Consumption: 13 W | Mass: 1.2 kg
