Qlight SHD2S Xenon Strobe Beacon with Dual Electronic Sounders, 114 dB x 2

Qlight SHD2S Xenon Strobe Beacon with Dual Electronic Sounders, 114 dB x 2

Xenon strobe beacon with two 114 dB electronic horns for vessels and heavy industry.

Key features

  • Xenon strobe (EUB0641-1A(G) lamp), 60-80 flashes/min
  • Two opposing horns
  • Signal beacon and electronic sounder combined in one rugged aluminum unit
  • 25 selectable sounds (5 warning, 5 special warning, 5 melodies, 5 alarms, 5 custom voices)
  • Volume and sound pattern set by internal switches
  • Customization: 3/4" PF entry, cable gland, external sound selection line (-LC)

Specifications

Protection rating IP66
Cable entry 1/2" PF
Housing color Munsell 7.5BG 7/2
Materials Lens PC, housing Al, cage STS316L
Sounds WS 5 warning sounds, WP 5 special warning sounds, WM 5 melodies, WA 5 alarms, WV 5 customizable voices
Colors R, A, G, B
Transistor input NPN
Light source Xenon strobe
Sound level Max. 114 dB x 2 at 1 m
Ambient temperature -30 to +50 °C
Voltage DC12V (4A), DC24V (2.4A), AC110V (580mA), AC220V (330mA)
SHD2S Type: standard | Weight: DC 4.11kg, AC 4.44kg
SHD2SP Type: protection cage | Weight: DC 4.36kg, AC 4.69kg
Sounder BeaconsQlight
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Qlight SHD2S Xenon Strobe Beacon with Dual Electronic Sounders, 114 dB x 2

Brand Qlight·Sounder Beacons

Available part numbers (2)

SHD2S, SHD2SP

How to order

Send the Qlight part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SHD2SType: standard | Weight: DC 4.11kg, AC 4.44kg
SHD2SPType: protection cage | Weight: DC 4.36kg, AC 4.69kg
