Samchully Closed-Center Hydraulic Cylinder with Proximity Bracket Y-RE-UN

Samchully Closed-Center Hydraulic Cylinder with Proximity Bracket Y-RE-UN

Standard closed-center hydraulic cylinder with proximity bracket, UN version.

Key features

  • Built-in lock valve maintains thrust on power failure or sudden pressure drop
  • Built-in relief valve prevents overpressure and cylinder damage

Specifications

Max. Operating Pressure (MPa (kgf/cm²)) 4.0 (40.8)
Total Leakage (ℓ/min) 0.8
Y-0715RE-UN Piston Stroke (mm): 15 | Piston Surface Area (Push) (cm²): 44 | Piston Surface Area (Pull) (cm²): 37 | Piston Force (Push) (kN (kgf)): 15.9 (1621) | Piston Force (Pull) (kN (kgf)): 13.9 (1417) | Max. Speed (rpm): 6000 | Weight (kg): 4
Y-1020RE-UN Piston Stroke (mm): 20 | Piston Surface Area (Push) (cm²): 84 | Piston Surface Area (Pull) (cm²): 79 | Piston Force (Push) (kN (kgf)): 31.0 (3161) | Piston Force (Pull) (kN (kgf)): 29 (2957) | Max. Speed (rpm): 6000 | Weight (kg): 7.6
Y-1025RE-UN Piston Stroke (mm): 25 | Piston Surface Area (Push) (cm²): 84 | Piston Surface Area (Pull) (cm²): 79 | Piston Force (Push) (kN (kgf)): 31.0 (3161) | Piston Force (Pull) (kN (kgf)): 29 (2957) | Max. Speed (rpm): 6000 | Weight (kg): 7.7
Y-1225RE-UN Piston Stroke (mm): 25 | Piston Surface Area (Push) (cm²): 120 | Piston Surface Area (Pull) (cm²): 113 | Piston Force (Push) (kN (kgf)): 45.0 (4589) | Piston Force (Pull) (kN (kgf)): 42 (4283) | Max. Speed (rpm): 6000 | Weight (kg): 10.5
Y-1240RE-UN Piston Stroke (mm): 40 | Piston Surface Area (Push) (cm²): 120 | Piston Surface Area (Pull) (cm²): 113 | Piston Force (Push) (kN (kgf)): 45.0 (4589) | Piston Force (Pull) (kN (kgf)): 42 (4283) | Max. Speed (rpm): 6000 | Weight (kg): 11
Y-1530RE-UN Piston Stroke (mm): 30 | Piston Surface Area (Push) (cm²): 174 | Piston Surface Area (Pull) (cm²): 160 | Piston Force (Push) (kN (kgf)): 65.0 (6628) | Piston Force (Pull) (kN (kgf)): 60 (6118) | Max. Speed (rpm): 5500 | Weight (kg): 14
Y-1550RE-UN Piston Stroke (mm): 50 | Piston Surface Area (Push) (cm²): 174 | Piston Surface Area (Pull) (cm²): 160 | Piston Force (Push) (kN (kgf)): 65.0 (6628) | Piston Force (Pull) (kN (kgf)): 60 (6118) | Max. Speed (rpm): 5500 | Weight (kg): 14.8
Y-2035RE-UN Piston Stroke (mm): 35 | Piston Surface Area (Push) (cm²): 312 | Piston Surface Area (Pull) (cm²): 290 | Piston Force (Push) (kN (kgf)): 117.0 (11934) | Piston Force (Pull) (kN (kgf)): 108 (11013) | Max. Speed (rpm): 5500 | Weight (kg): 22.5
Y-2050RE-UN Piston Stroke (mm): 50 | Piston Surface Area (Push) (cm²): 312 | Piston Surface Area (Pull) (cm²): 290 | Piston Force (Push) (kN (kgf)): 117.0 (11934) | Piston Force (Pull) (kN (kgf)): 108 (11013) | Max. Speed (rpm): 5500 | Weight (kg): 23.5
Y-2560RE-UN Piston Stroke (mm): 60 | Piston Surface Area (Push) (cm²): 515 | Piston Surface Area (Pull) (cm²): 482 | Piston Force (Push) (kN (kgf)): 154 (15759) | Piston Force (Pull) (kN (kgf)): 144.5 (14749) | Max. Speed (rpm): 2000 | Weight (kg): 85
Rotary CylindersSamchully
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samchully Closed-Center Hydraulic Cylinder with Proximity Bracket Y-RE-UN

Brand Samchully·Rotary Cylinders

Available part numbers (10)

Y-0715RE-UN, Y-1020RE-UN, Y-1025RE-UN, Y-1225RE-UN, Y-1240RE-UN, Y-1530RE-UN, Y-1550RE-UN, Y-2035RE-UN, Y-2050RE-UN, Y-2560RE-UN
