Samyang Reducer MAX Gear Head, IEC Flange Type (0.4–7.5 kW)

Samyang Reducer MAX Gear Head, IEC Flange Type (0.4–7.5 kW)

Samyang MAX helical gear heads with an IEC motor flange input, accepting standard 4-pole or 6-pole IEC flange motors from 0.4 to 7.5 kW.

Key features

  • Designation as printed by Samyang, e.g. GMSM153H30 (frame 153, ratio 1:30)
  • Two-stage helical gear train with IEC motor flange and bracket, foot-mounted case
  • Motor flange sizes LA 130 to 265 mm matched to 4P motor output 0.4 to 7.5 kW
  • Frames F105 to F270, ratios 1:5 to 1:60
  • Mates with Samyang 3-phase IEC flange motors (TEFC, insulation class B)

Specifications

Series MAX gear head
Input IEC flange for motor mounting
Mounting Horizontal, foot mount
Gearing Two-stage helical
Motor basis 60 Hz, 4P or 6P
Ratio range 1:5 to 1:60
Source Samyang MAX Geared Motor catalog, p. 1-21 to 1-23
GMSM105H5 Frame: F105 | Ratio: 1:5 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H10 Frame: F105 | Ratio: 1:10 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H20 Frame: F105 | Ratio: 1:20 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H30 Frame: F105 | Ratio: 1:30 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H40 Frame: F105 | Ratio: 1:40 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H50 Frame: F105 | Ratio: 1:50 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM105H60 Frame: F105 | Ratio: 1:60 | Motor 4P (60 Hz): 0.4 kW | Motor 6P (60 Hz): n/a | Flange LA/LB/LC: 130/110/160 mm
GMSM135H5 Frame: F135 | Ratio: 1:5 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM135H10 Frame: F135 | Ratio: 1:10 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM135H20 Frame: F135 | Ratio: 1:20 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM135H30 Frame: F135 | Ratio: 1:30 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H5 Frame: F153 | Ratio: 1:5 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H10 Frame: F153 | Ratio: 1:10 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H20 Frame: F153 | Ratio: 1:20 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H30 Frame: F153 | Ratio: 1:30 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H40 Frame: F153 | Ratio: 1:40 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H50 Frame: F153 | Ratio: 1:50 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM153H60 Frame: F153 | Ratio: 1:60 | Motor 4P (60 Hz): 0.75 kW | Motor 6P (60 Hz): 0.4 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM172H5 Frame: F172 | Ratio: 1:5 | Motor 4P (60 Hz): 2.2 / 3.7 kW | Motor 6P (60 Hz): 1.5 / 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM172H10 Frame: F172 | Ratio: 1:10 | Motor 4P (60 Hz): 2.2 / 3.7 kW | Motor 6P (60 Hz): 1.5 / 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM172H20 Frame: F172 | Ratio: 1:20 | Motor 4P (60 Hz): 2.2 / 3.7 kW | Motor 6P (60 Hz): 1.5 / 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM172H30 Frame: F172 | Ratio: 1:30 | Motor 4P (60 Hz): 2.2 kW | Motor 6P (60 Hz): 1.5 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM172H40 Frame: F172 | Ratio: 1:40 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM172H50 Frame: F172 | Ratio: 1:50 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM172H60 Frame: F172 | Ratio: 1:60 | Motor 4P (60 Hz): 1.5 kW | Motor 6P (60 Hz): 0.75 kW | Flange LA/LB/LC: 165/130/200 mm
GMSM181H5 Frame: F181 | Ratio: 1:5 | Motor 4P (60 Hz): 5.5 / 7.5 kW | Motor 6P (60 Hz): 3.7 / 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM181H10 Frame: F181 | Ratio: 1:10 | Motor 4P (60 Hz): 5.5 / 7.5 kW | Motor 6P (60 Hz): 3.7 / 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM181H20 Frame: F181 | Ratio: 1:20 | Motor 4P (60 Hz): 5.5 kW | Motor 6P (60 Hz): 3.7 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM181H30 Frame: F181 | Ratio: 1:30 | Motor 4P (60 Hz): 3.7 kW | Motor 6P (60 Hz): 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM181H40 Frame: F181 | Ratio: 1:40 | Motor 4P (60 Hz): 2.2 kW | Motor 6P (60 Hz): 1.5 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM181H50 Frame: F181 | Ratio: 1:50 | Motor 4P (60 Hz): 2.2 kW | Motor 6P (60 Hz): 1.5 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM205H20 Frame: F205 | Ratio: 1:20 | Motor 4P (60 Hz): 7.5 kW | Motor 6P (60 Hz): 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM205H30 Frame: F205 | Ratio: 1:30 | Motor 4P (60 Hz): 5.5 kW | Motor 6P (60 Hz): 3.7 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM205H40 Frame: F205 | Ratio: 1:40 | Motor 4P (60 Hz): 3.7 kW | Motor 6P (60 Hz): 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM205H50 Frame: F205 | Ratio: 1:50 | Motor 4P (60 Hz): 3.7 kW | Motor 6P (60 Hz): 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM205H60 Frame: F205 | Ratio: 1:60 | Motor 4P (60 Hz): 2.2 kW | Motor 6P (60 Hz): 1.5 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM235H30 Frame: F235 | Ratio: 1:30 | Motor 4P (60 Hz): 7.5 kW | Motor 6P (60 Hz): 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM235H40 Frame: F235 | Ratio: 1:40 | Motor 4P (60 Hz): 5.5 kW | Motor 6P (60 Hz): 3.7 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM235H50 Frame: F235 | Ratio: 1:50 | Motor 4P (60 Hz): 5.5 kW | Motor 6P (60 Hz): 3.7 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM235H60 Frame: F235 | Ratio: 1:60 | Motor 4P (60 Hz): 3.7 kW | Motor 6P (60 Hz): 2.2 kW | Flange LA/LB/LC: 215/180/250 mm
GMSM270H40 Frame: F270 | Ratio: 1:40 | Motor 4P (60 Hz): 7.5 kW | Motor 6P (60 Hz): 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM270H50 Frame: F270 | Ratio: 1:50 | Motor 4P (60 Hz): 7.5 kW | Motor 6P (60 Hz): 5.5 kW | Flange LA/LB/LC: 265/230/300 mm
GMSM270H60 Frame: F270 | Ratio: 1:60 | Motor 4P (60 Hz): 5.5 kW | Motor 6P (60 Hz): 3.7 kW | Flange LA/LB/LC: 265/230/300 mm
Geared MotorsSamyang Reducer
43 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samyang Reducer MAX Gear Head, IEC Flange Type (0.4–7.5 kW)

Brand Samyang Reducer·Geared Motors

Available part numbers (43)

GMSM105H5, GMSM105H10, GMSM105H20, GMSM105H30, GMSM105H40, GMSM105H50, GMSM105H60, GMSM135H5, GMSM135H10, GMSM135H20 + 33 more — see full table ↓

How to order

Send the Samyang Reducer part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
