SKF TIH L Series Large Induction Heaters (TIH L33, L44, L77)

SKF TIH L Series Large Induction Heaters (TIH L33, L44, L77)

SKF TIH L series induction heaters are high-power, large-size heaters with dual coils and sliding yokes for fast and safe hot mounting of large bearings up to 1 200 kg.

Key features

  • Dual coil design for horizontal or vertical bearing heating
  • More homogeneous heating and additional safety for large bearings
  • Robust sliding yoke mechanism; optional smaller yokes
  • Frame allows transport by fork lift
  • Available in LV (200-240 V) and MV (400-460 V) executions

Specifications

Demagnetisation <2 A/cm
Source SKF Maintenance and Lubrication Products, p. 48-49
TIH L33/LV Max. bearing weight: 700 kg | Bore range: 115-700 mm | Voltage: 200-240 V | Max. power: 15 kVA | Weight: 140 kg
TIH L33/MV Max. bearing weight: 700 kg | Bore range: 115-700 mm | Voltage: 400-460 V | Max. power: 15 kVA | Weight: 140 kg
TIH L44/LV Max. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 200-240 V | Max. power: 20-24 kVA | Weight: 324 kg
TIH L44/MV Max. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 400-460 V | Max. power: 20-23 kVA | Weight: 324 kg
TIH L77/LV Max. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 200-240 V | Max. power: 20-24 kVA | Weight: 415 kg
TIH L77/MV Max. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 400-460 V | Max. power: 20-23 kVA | Weight: 415 kg
Induction HeatersSKF
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF TIH L Series Large Induction Heaters (TIH L33, L44, L77)

Brand SKF·Induction Heaters

Available part numbers (6)

TIH L33/LV, TIH L33/MV, TIH L44/LV, TIH L44/MV, TIH L77/LV, TIH L77/MV

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TIH L33/LVMax. bearing weight: 700 kg | Bore range: 115-700 mm | Voltage: 200-240 V | Max. power: 15 kVA | Weight: 140 kg
TIH L33/MVMax. bearing weight: 700 kg | Bore range: 115-700 mm | Voltage: 400-460 V | Max. power: 15 kVA | Weight: 140 kg
TIH L44/LVMax. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 200-240 V | Max. power: 20-24 kVA | Weight: 324 kg
TIH L44/MVMax. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 400-460 V | Max. power: 20-23 kVA | Weight: 324 kg
TIH L77/LVMax. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 200-240 V | Max. power: 20-24 kVA | Weight: 415 kg
TIH L77/MVMax. bearing weight: 1 200 kg | Bore range: 150-800 mm | Voltage: 400-460 V | Max. power: 20-23 kVA | Weight: 415 kg
