SKF TLMP MultiPoint Automatic Lubricators (8 or 18 Outlets)

SKF TLMP MultiPoint Automatic Lubricators (8 or 18 Outlets)

SKF TLMP multipoint automatic lubricators are complete ready-to-use lubrication kits supplying grease to one to eighteen lubrication points from a 1 litre reservoir.

Key features

  • Complete kit with pump, tubing and connectors
  • Keypad programming with LED display
  • Stirring paddle prevents grease separation
  • Low-level and blocked-line alarms; machine steering by removing power
  • IP 67, vibration resistant; 24 V DC, 120 V AC and 230 V AC versions

Specifications

Max. pressure 205 bar
Reservoir 1 litre
Grease NLGI 2, 3
Dispense rate 0.1-40 cm3/day per outlet
IP rating IP 67
Source SKF Maintenance and Lubrication Products, p. 170-171
TLMP 1008/24DC Outlets: 1-8 | Voltage: 24 V DC | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1008/120V Outlets: 1-8 | Voltage: 120 V AC 60 Hz | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1008/230V Outlets: 1-8 | Voltage: 230 V AC 50 Hz | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1018/24DC Outlets: 1-18 | Voltage: 24 V DC | Tubing: 50 m nylon 6 x 1.5 mm
TLMP 1018/120V Outlets: 1-18 | Voltage: 120 V AC 60 Hz | Tubing: 50 m nylon 6 x 1.5 mm
TLMP 1018/230V Outlets: 1-18 | Voltage: 230 V AC 50 Hz | Tubing: 50 m nylon 6 x 1.5 mm
LubricatorsSKF
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF TLMP MultiPoint Automatic Lubricators (8 or 18 Outlets)

Brand SKF·Lubricators

Available part numbers (6)

TLMP 1008/24DC, TLMP 1008/120V, TLMP 1008/230V, TLMP 1018/24DC, TLMP 1018/120V, TLMP 1018/230V

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TLMP 1008/24DCOutlets: 1-8 | Voltage: 24 V DC | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1008/120VOutlets: 1-8 | Voltage: 120 V AC 60 Hz | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1008/230VOutlets: 1-8 | Voltage: 230 V AC 50 Hz | Tubing: 20 m nylon 6 x 1.5 mm
TLMP 1018/24DCOutlets: 1-18 | Voltage: 24 V DC | Tubing: 50 m nylon 6 x 1.5 mm
TLMP 1018/120VOutlets: 1-18 | Voltage: 120 V AC 60 Hz | Tubing: 50 m nylon 6 x 1.5 mm
TLMP 1018/230VOutlets: 1-18 | Voltage: 230 V AC 50 Hz | Tubing: 50 m nylon 6 x 1.5 mm
