    SMC GP46 Pressure Gauge with Switch (1.0 MPa, Limit Indicator)

    SMC GP46 Pressure Gauge with Switch (1.0 MPa, Limit Indicator)

    SMC GP46 pressure gauge with built-in micro switch, adding a pressure switch function and optional lamp to a ø42.5 gauge.

    Key features

    • Micro switch (1ab) with setting pointer, set range 0.1 to 0.8 MPa on a 0 to 1.0 MPa gauge
    • Indicator lamp: none, neon lamp AC100 to 220V (L2) or LED DC24V (L5); lamp lights below set pressure
    • R1/8 or R1/4 rear thread; option M adds M5 female port
    • Panel mounting with covering ring C or C2; limit indicator
    • Options: X201 3 m lead wire, Q CE/UKCA marking, X30 MPa/psi

    Specifications

    Pressure range 0 to 1.0 MPa
    Switch setting range 0.1 to 0.8 MPa
    Hysteresis 0.07 MPa or less
    Setting error ±0.05 MPa (5 to 40°C)
    Contact 1ab micro switch (NO/NC), lead wire 300 mm
    Switch rating DC30V 0.01-0.5A, AC125V 0.01-0.3A, AC250V 0.01-0.2A
    Fluid / temperature Air / -5 to 60°C
    Accuracy ±0.03 MPa
    Mass 0.12 kg
    Special X201 lead wire 3 m, Q CE/UKCA, X30 MPa/psi
    Source SMC Korea catalog GP46 (SMCKR_GP46.pdf), p. 1296-1297 (PDF p. 1-2)
    GP46-10-01 Connection: R1/8 | Indicator lamp: None | Covering ring: None | Availability: Stock item
    GP46-10-01-C Connection: R1/8 | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01-C2 Connection: R1/8 | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01L2 Connection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Stock item
    GP46-10-01L2-C Connection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01L2-C2 Connection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01L5 Connection: R1/8 | Indicator lamp: LED DC24V | Covering ring: None | Availability: Stock item
    GP46-10-01L5-C Connection: R1/8 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01L5-C2 Connection: R1/8 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01M Connection: R1/8 + M5 female | Indicator lamp: None | Covering ring: None | Availability: Made to order
    GP46-10-01M-C Connection: R1/8 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01M-C2 Connection: R1/8 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01ML2 Connection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Made to order
    GP46-10-01ML2-C Connection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01ML2-C2 Connection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01ML5 Connection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: None | Availability: Made to order
    GP46-10-01ML5-C Connection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01ML5-C2 Connection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02 Connection: R1/4 | Indicator lamp: None | Covering ring: None | Availability: Stock item
    GP46-10-02-C Connection: R1/4 | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02-C2 Connection: R1/4 | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02L2 Connection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Stock item
    GP46-10-02L2-C Connection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02L2-C2 Connection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02L5 Connection: R1/4 | Indicator lamp: LED DC24V | Covering ring: None | Availability: Stock item
    GP46-10-02L5-C Connection: R1/4 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02L5-C2 Connection: R1/4 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02M Connection: R1/4 + M5 female | Indicator lamp: None | Covering ring: None | Availability: Made to order
    GP46-10-02M-C Connection: R1/4 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02M-C2 Connection: R1/4 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02ML2 Connection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Made to order
    GP46-10-02ML2-C Connection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02ML2-C2 Connection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02ML5 Connection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: None | Availability: Made to order
    GP46-10-02ML5-C Connection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02ML5-C2 Connection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    Pressure GaugesSMC
    36 product codes available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    SMC GP46 Pressure Gauge with Switch (1.0 MPa, Limit Indicator)

    Brand SMC·Pressure Gauges

    Available part numbers (36)

    GP46-10-01, GP46-10-01-C, GP46-10-01-C2, GP46-10-01L2, GP46-10-01L2-C, GP46-10-01L2-C2, GP46-10-01L5, GP46-10-01L5-C, GP46-10-01L5-C2, GP46-10-01M + 26 more — see full table ↓

    How to order

    Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

    RFQ List 0 →
    View full details
    Product codes & specifications
    0 selected
    RFQ List (0)
    Product codeSpec
    GP46-10-01Connection: R1/8 | Indicator lamp: None | Covering ring: None | Availability: Stock item
    GP46-10-01-CConnection: R1/8 | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01-C2Connection: R1/8 | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01L2Connection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Stock item
    GP46-10-01L2-CConnection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01L2-C2Connection: R1/8 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01L5Connection: R1/8 | Indicator lamp: LED DC24V | Covering ring: None | Availability: Stock item
    GP46-10-01L5-CConnection: R1/8 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01L5-C2Connection: R1/8 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01MConnection: R1/8 + M5 female | Indicator lamp: None | Covering ring: None | Availability: Made to order
    GP46-10-01M-CConnection: R1/8 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01M-C2Connection: R1/8 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01ML2Connection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Made to order
    GP46-10-01ML2-CConnection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01ML2-C2Connection: R1/8 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-01ML5Connection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: None | Availability: Made to order
    GP46-10-01ML5-CConnection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-01ML5-C2Connection: R1/8 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02Connection: R1/4 | Indicator lamp: None | Covering ring: None | Availability: Stock item
    GP46-10-02-CConnection: R1/4 | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02-C2Connection: R1/4 | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02L2Connection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Stock item
    GP46-10-02L2-CConnection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02L2-C2Connection: R1/4 | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02L5Connection: R1/4 | Indicator lamp: LED DC24V | Covering ring: None | Availability: Stock item
    GP46-10-02L5-CConnection: R1/4 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02L5-C2Connection: R1/4 | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02MConnection: R1/4 + M5 female | Indicator lamp: None | Covering ring: None | Availability: Made to order
    GP46-10-02M-CConnection: R1/4 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02M-C2Connection: R1/4 + M5 female | Indicator lamp: None | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02ML2Connection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: None | Availability: Made to order
    GP46-10-02ML2-CConnection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02ML2-C2Connection: R1/4 + M5 female | Indicator lamp: Neon lamp AC100 to 220V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
    GP46-10-02ML5Connection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: None | Availability: Made to order
    GP46-10-02ML5-CConnection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover fixed (C) | Availability: Made to order
    GP46-10-02ML5-C2Connection: R1/4 + M5 female | Indicator lamp: LED DC24V | Covering ring: Covering ring, cover removable (C2) | Availability: Made to order
