SPG SG 90 mm Electromagnetic Brake Motors (Lead Wire, 40–90 W)

SPG SG 90 mm Electromagnetic Brake Motors (Lead Wire, 40–90 W)

SPG SG series 90 mm square-flange AC electromagnetic brake motors, 40–90 W, lead-wire type, with a power-off (non-excitation) brake that stops the shaft and holds the load when power is removed.

Key features

  • AC non-excitation run electromagnetic brake mounted at the motor rear; brake engages instantly at power off and holds the load
  • Brake has a built-in rectifier and runs from the same AC supply as the motor; holding force 0.5 to 10 kgf·cm across the range
  • Single-phase versions are built on reversible motors (S2 30 min rating); three-phase versions on induction motors (continuous rating)
  • Shaft options: pinion (gear type) for SG gearheads, key, D-cut or straight round shaft
  • Two capacitor values per voltage code; specify AC 100 V or 200 V operation when ordering
  • Gearheads are sold separately (SG K/D/S-type gearheads of the same frame)

Specifications

Frame size 90 mm square
Poles 4
Insulation class B (130 °C)
Degree of protection IP23
Overheat protection Thermal protector (T.P.), auto reset
Rated speed 1250-1350 r/min (50 Hz), 1500-1650 r/min (60 Hz)
Lead wire Lead wire type, 300 mm
Certifications UL, TUV, CCC (CE marked)
Source SPG Standard SG AC Geared Motor catalog, p. 63-65, 72-77
SG9R40GA-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 16.0 uF @100 V / 12.0 uF @110-115 V | Duty: S2 (30 min)
SG9R40KA-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 16.0 uF @100 V / 12.0 uF @110-115 V | Duty: S2 (30 min)
SG9R40DA-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 16.0 uF @100 V / 12.0 uF @110-115 V | Duty: S2 (30 min)
SG9R40SA-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 16.0 uF @100 V / 12.0 uF @110-115 V | Duty: S2 (30 min)
SG9R40GB-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 4.0 uF @200 V / 3.5 uF @220-230 V | Duty: S2 (30 min)
SG9R40KB-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 4.0 uF @200 V / 3.5 uF @220-230 V | Duty: S2 (30 min)
SG9R40DB-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 4.0 uF @200 V / 3.5 uF @220-230 V | Duty: S2 (30 min)
SG9R40SB-E Output: 40 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 4.0 uF @200 V / 3.5 uF @220-230 V | Duty: S2 (30 min)
SG9I40GT-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40KT-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40DT-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40ST-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40GS-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40KS-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40DS-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I40SS-E Output: 40 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9R60GA-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R60KA-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R60DA-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R60SA-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R60GB-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R60KB-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R60DB-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R60SB-E Output: 60 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9I60GT-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60KT-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60DT-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60ST-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60GS-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60KS-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60DS-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I60SS-E Output: 60 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9R90GA-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R90KA-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R90DA-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R90SA-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Capacitor: 25.0 uF @100 V / 20.0 uF @110-115 V | Duty: S2 (30 min)
SG9R90GB-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Pinion (gear type) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R90KB-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Key | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R90DB-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: D-cut | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9R90SB-E Output: 90 W | Motor type: Reversible, 1-phase | Shaft: Straight (round) | Power supply: 1-ph 200/220/230 V 50/60 Hz | Capacitor: 6.0 uF @200 V / 5.0 uF @220-230 V | Duty: S2 (30 min)
SG9I90GT-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90KT-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90DT-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90ST-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 200/220/230 V 50/60 Hz | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90GS-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Pinion (gear type) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90KS-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Key | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90DS-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: D-cut | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
SG9I90SS-E Output: 90 W | Motor type: Induction, 3-phase | Shaft: Straight (round) | Power supply: 3-ph 380/400/415/440 V | Capacitor: None (3-phase) | Duty: S1 (continuous)
Brake MotorsSPG
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG SG 90 mm Electromagnetic Brake Motors (Lead Wire, 40–90 W)

Brand SPG·Brake Motors

Available part numbers (48)

SG9R40GA-E, SG9R40KA-E, SG9R40DA-E, SG9R40SA-E, SG9R40GB-E, SG9R40KB-E, SG9R40DB-E, SG9R40SB-E, SG9I40GT-E, SG9I40KT-E + 38 more — see full table ↓

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
