• SPG SG Motor and Gearhead Mounting Plates (60-90 mm)
1 1

SPG SG Motor and Gearhead Mounting Plates (60-90 mm)

SPG SG Motor and Gearhead Mounting Plates (60-90 mm)

SPG SPL series aluminium L-type foot mounting plates for 60, 70, 80 and 90 mm frame SG motors and gearheads.

Key features

  • Angle (L-type) foot bracket for mounting a motor or gearhead flange to a base
  • One model per frame size: SPL-6A (60 mm), SPL-7B (70 mm), SPL-8B (80 mm), SPL-9SB (90 mm)
  • Slotted foot holes for position adjustment
  • Lightweight aluminium construction, 45-270 g
  • Sold separately from motors and gearheads

Specifications

Material Aluminium
Type L-type foot mounting plate
Applicable SG motors and gearheads
Sold Separately
Units mm
Source SPG Standard SG AC Geared Motor catalog, p. 224-225
SPL-7B Frame: 70 mm | Base width: 110 mm | Shaft centre height: 48 mm | Mounting tap: 4-M6 x P1.0 | Weight: 75 g
SPL-8B Frame: 80 mm | Base width: 120 mm | Shaft centre height: 55 mm | Mounting tap: 4-M6 x P1.0 | Weight: 120 g
Motor AccessoriesSPG
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG SG Motor and Gearhead Mounting Plates (60-90 mm)

Brand SPG·Motor Accessories

Available part numbers (2)

SPL-7B, SPL-8B

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SPL-7BFrame: 70 mm | Base width: 110 mm | Shaft centre height: 48 mm | Mounting tap: 4-M6 x P1.0 | Weight: 75 g
SPL-8BFrame: 80 mm | Base width: 120 mm | Shaft centre height: 55 mm | Mounting tap: 4-M6 x P1.0 | Weight: 120 g
