THK Cross Roller Guide VR15

THK Cross Roller Guide VR15

Cross Roller Guide VR15 type.

Key features

  • Rail length 300~1200mm, 8~33 rollers per set
  • Basic dynamic load rating C_Z = 27.9 kN per roller; static C0Z = 26.8 kN per roller. 4-rail + 2-cage assembly (1 set)
  • Roller diameter 15.081 mm (cross arrangement)
  • Stainless type (VR15M) available on request

Specifications

Roller Diameter 15.081 mm (cross roller)
Basic Dynamic Load Rating C_Z 27.9 kN (per roller)
Basic Static Load Rating C0Z 26.8 kN (per roller)
Rail Mass 8.3 kg/m (rail)
Assembly 4 rails + 2 cages (1 set)
Stainless Type VR15M (order basis)
VR15-300x8Z THK Cross Roller Guide VR15, Rail 300mm, 8 rollers, max stroke 190mm | Rail Length: 300 mm | Rollers (Z): 8 | Max Stroke: 190 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-400x11Z THK Cross Roller Guide VR15, Rail 400mm, 11 rollers, max stroke 240mm | Rail Length: 400 mm | Rollers (Z): 11 | Max Stroke: 240 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-500x13Z THK Cross Roller Guide VR15, Rail 500mm, 13 rollers, max stroke 340mm | Rail Length: 500 mm | Rollers (Z): 13 | Max Stroke: 340 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-600x16Z THK Cross Roller Guide VR15, Rail 600mm, 16 rollers, max stroke 390mm | Rail Length: 600 mm | Rollers (Z): 16 | Max Stroke: 390 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-700x19Z THK Cross Roller Guide VR15, Rail 700mm, 19 rollers, max stroke 440mm | Rail Length: 700 mm | Rollers (Z): 19 | Max Stroke: 440 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-800x22Z THK Cross Roller Guide VR15, Rail 800mm, 22 rollers, max stroke 490mm | Rail Length: 800 mm | Rollers (Z): 22 | Max Stroke: 490 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-900x25Z THK Cross Roller Guide VR15, Rail 900mm, 25 rollers, max stroke 540mm | Rail Length: 900 mm | Rollers (Z): 25 | Max Stroke: 540 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-1000x27Z THK Cross Roller Guide VR15, Rail 1000mm, 27 rollers, max stroke 640mm | Rail Length: 1000 mm | Rollers (Z): 27 | Max Stroke: 640 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-1100x30Z THK Cross Roller Guide VR15, Rail 1100mm, 30 rollers, max stroke 690mm | Rail Length: 1100 mm | Rollers (Z): 30 | Max Stroke: 690 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
VR15-1200x33Z THK Cross Roller Guide VR15, Rail 1200mm, 33 rollers, max stroke 740mm | Rail Length: 1200 mm | Rollers (Z): 33 | Max Stroke: 740 mm | Roller Diameter: 15.081 mm (cross roller) | Basic Dynamic Load Rating C_Z: 27.9 kN (per roller) | Basic Static Load Rating C0Z: 26.8 kN (per roller) | Rail Mass: 8.3 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR15M (order basis)
