THK Cross Roller Guide VR18

THK Cross Roller Guide VR18

Cross Roller Guide VR18 type.

Key features

  • Rail length 300~1200mm, 6~27 rollers per set
  • Basic dynamic load rating C_Z = 40.9 kN per roller; static C0Z = 38.8 kN per roller. 4-rail + 2-cage assembly (1 set)
  • Roller diameter 18 mm (cross arrangement)
  • Stainless type (VR18M) available on request

Specifications

Roller Diameter 18 mm (cross roller)
Basic Dynamic Load Rating C_Z 40.9 kN (per roller)
Basic Static Load Rating C0Z 38.8 kN (per roller)
Rail Mass 10.5 kg/m (rail)
Assembly 4 rails + 2 cages (1 set)
Stainless Type VR18M (order basis)
VR18-300x6Z THK Cross Roller Guide VR18, Rail 300mm, 6 rollers, max stroke 228mm | Rail Length: 300 mm | Rollers (Z): 6 | Max Stroke: 228 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-400x9Z THK Cross Roller Guide VR18, Rail 400mm, 9 rollers, max stroke 248mm | Rail Length: 400 mm | Rollers (Z): 9 | Max Stroke: 248 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-500x11Z THK Cross Roller Guide VR18, Rail 500mm, 11 rollers, max stroke 328mm | Rail Length: 500 mm | Rollers (Z): 11 | Max Stroke: 328 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-600x13Z THK Cross Roller Guide VR18, Rail 600mm, 13 rollers, max stroke 408mm | Rail Length: 600 mm | Rollers (Z): 13 | Max Stroke: 408 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-700x16Z THK Cross Roller Guide VR18, Rail 700mm, 16 rollers, max stroke 428mm | Rail Length: 700 mm | Rollers (Z): 16 | Max Stroke: 428 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-800x18Z THK Cross Roller Guide VR18, Rail 800mm, 18 rollers, max stroke 508mm | Rail Length: 800 mm | Rollers (Z): 18 | Max Stroke: 508 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-900x20Z THK Cross Roller Guide VR18, Rail 900mm, 20 rollers, max stroke 588mm | Rail Length: 900 mm | Rollers (Z): 20 | Max Stroke: 588 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1000x23Z THK Cross Roller Guide VR18, Rail 1000mm, 23 rollers, max stroke 608mm | Rail Length: 1000 mm | Rollers (Z): 23 | Max Stroke: 608 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1100x25Z THK Cross Roller Guide VR18, Rail 1100mm, 25 rollers, max stroke 688mm | Rail Length: 1100 mm | Rollers (Z): 25 | Max Stroke: 688 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1200x27Z THK Cross Roller Guide VR18, Rail 1200mm, 27 rollers, max stroke 768mm | Rail Length: 1200 mm | Rollers (Z): 27 | Max Stroke: 768 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
Roller GuidesTHK
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK Cross Roller Guide VR18

Brand THK·Roller Guides

Available part numbers (10)

VR18-300x6Z, VR18-400x9Z, VR18-500x11Z, VR18-600x13Z, VR18-700x16Z, VR18-800x18Z, VR18-900x20Z, VR18-1000x23Z, VR18-1100x25Z, VR18-1200x27Z

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VR18-300x6ZTHK Cross Roller Guide VR18, Rail 300mm, 6 rollers, max stroke 228mm | Rail Length: 300 mm | Rollers (Z): 6 | Max Stroke: 228 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-400x9ZTHK Cross Roller Guide VR18, Rail 400mm, 9 rollers, max stroke 248mm | Rail Length: 400 mm | Rollers (Z): 9 | Max Stroke: 248 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-500x11ZTHK Cross Roller Guide VR18, Rail 500mm, 11 rollers, max stroke 328mm | Rail Length: 500 mm | Rollers (Z): 11 | Max Stroke: 328 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-600x13ZTHK Cross Roller Guide VR18, Rail 600mm, 13 rollers, max stroke 408mm | Rail Length: 600 mm | Rollers (Z): 13 | Max Stroke: 408 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-700x16ZTHK Cross Roller Guide VR18, Rail 700mm, 16 rollers, max stroke 428mm | Rail Length: 700 mm | Rollers (Z): 16 | Max Stroke: 428 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-800x18ZTHK Cross Roller Guide VR18, Rail 800mm, 18 rollers, max stroke 508mm | Rail Length: 800 mm | Rollers (Z): 18 | Max Stroke: 508 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-900x20ZTHK Cross Roller Guide VR18, Rail 900mm, 20 rollers, max stroke 588mm | Rail Length: 900 mm | Rollers (Z): 20 | Max Stroke: 588 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1000x23ZTHK Cross Roller Guide VR18, Rail 1000mm, 23 rollers, max stroke 608mm | Rail Length: 1000 mm | Rollers (Z): 23 | Max Stroke: 608 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1100x25ZTHK Cross Roller Guide VR18, Rail 1100mm, 25 rollers, max stroke 688mm | Rail Length: 1100 mm | Rollers (Z): 25 | Max Stroke: 688 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
VR18-1200x27ZTHK Cross Roller Guide VR18, Rail 1200mm, 27 rollers, max stroke 768mm | Rail Length: 1200 mm | Rollers (Z): 27 | Max Stroke: 768 mm | Roller Diameter: 18 mm (cross roller) | Basic Dynamic Load Rating C_Z: 40.9 kN (per roller) | Basic Static Load Rating C0Z: 38.8 kN (per roller) | Rail Mass: 10.5 kg/m (rail) | Assembly: 4 rails + 2 cages (1 set) | Stainless Type: VR18M (order basis)
