THK Cross Roller Table VRU4 (W80×H35, M5)

THK Cross Roller Table VRU4 (W80×H35, M5)

THK VRU Cross Roller Table, VRU4 frame.

Key features

  • Table width W=80mm, height M=35mm, table mounting tap M5
  • Base mounting through-hole d×D×h = 5.5×9.5×6mm
  • Stroke range 50~185mm
  • Side mounting taps provided
  • Stainless steel type available on request (approx. 0.75~2.6 kg)

Specifications

Frame VRU4
Table Width (W) 80 mm
Height (M) 35 mm
Table Mounting Tap M5
Base Hole (d×D×h) 5.5×9.5×6 mm
Stainless Type available on request
VRU4085 THK Cross Roller Table VRU4085, stroke 50mm, 10 rollers, 1.5kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 50 mm | Rollers (Z): 10 | Mass (standard): 1.5 kg | Mass (stainless): 0.8 kg | Basic Dynamic Load Rating C: 5.9 kN | Basic Static Load Rating C0: 8.11 kN | Static Allowable Moment MA: 64.9 N·m | Static Allowable Moment MB: 57.4 N·m | Static Allowable Moment MC: 162.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
VRU4125 THK Cross Roller Table VRU4125, stroke 75mm, 11 rollers, 2.3kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 75 mm | Rollers (Z): 11 | Mass (standard): 2.3 kg | Mass (stainless): 1.2 kg | Basic Dynamic Load Rating C: 8.82 kN | Basic Static Load Rating C0: 13.5 kN | Static Allowable Moment MA: 147.0 N·m | Static Allowable Moment MB: 134.0 N·m | Static Allowable Moment MC: 270.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
VRU4165 THK Cross Roller Table VRU4165, stroke 105mm, 14 rollers, 3.1kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 105 mm | Rollers (Z): 14 | Mass (standard): 3.1 kg | Mass (stainless): 1.5 kg | Basic Dynamic Load Rating C: 11.5 kN | Basic Static Load Rating C0: 18.9 kN | Static Allowable Moment MA: 200.0 N·m | Static Allowable Moment MB: 214.0 N·m | Static Allowable Moment MC: 378.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
VRU4205 THK Cross Roller Table VRU4205, stroke 135mm, 18 rollers, 3.8kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 135 mm | Rollers (Z): 18 | Mass (standard): 3.8 kg | Mass (stainless): 1.9 kg | Basic Dynamic Load Rating C: 14.0 kN | Basic Static Load Rating C0: 24.3 kN | Static Allowable Moment MA: 330.0 N·m | Static Allowable Moment MB: 347.0 N·m | Static Allowable Moment MC: 486.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
VRU4245 THK Cross Roller Table VRU4245, stroke 155mm, 22 rollers, 4.6kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 155 mm | Rollers (Z): 22 | Mass (standard): 4.6 kg | Mass (stainless): 2.2 kg | Basic Dynamic Load Rating C: 16.3 kN | Basic Static Load Rating C0: 29.7 kN | Static Allowable Moment MA: 492.0 N·m | Static Allowable Moment MB: 513.0 N·m | Static Allowable Moment MC: 594.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
VRU4285 THK Cross Roller Table VRU4285, stroke 185mm, 26 rollers, 5.3kg | Frame: VRU4 | Table Width (W): 80 mm | Height (M): 35 mm | Stroke: 185 mm | Rollers (Z): 26 | Mass (standard): 5.3 kg | Mass (stainless): 2.6 kg | Basic Dynamic Load Rating C: 18.6 kN | Basic Static Load Rating C0: 35.1 kN | Static Allowable Moment MA: 687.0 N·m | Static Allowable Moment MB: 711.0 N·m | Static Allowable Moment MC: 703.0 N·m | Table Mounting Tap: M5 | Base Hole (d×D×h): 5.5×9.5×6 mm | Stainless Type: available on request
Roller GuidesTHK
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK Cross Roller Table VRU4 (W80×H35, M5)

Brand THK·Roller Guides

Available part numbers (6)

VRU4085, VRU4125, VRU4165, VRU4205, VRU4245, VRU4285

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
