THK LMJK-L Linear Bush Plastic Square Flange Long Type (LMJK8L~LMJK25L)

THK LMJK-L Linear Bush Plastic Square Flange Long Type (LMJK8L~LMJK25L)

LMJK-L type Linear Bush — high-strength plastic square flange, long type.

Key features

  • Lighter weight than metal flange type
  • Two retainers for moment load applications
  • Shaft diameters: 8~25mm
  • Synthetic resin retainer (max 80°C)
  • Seal option available on order

Specifications

Flange Material High-strength plastic (lightweight)
Type Long type (2 retainers)
Max Temp. 80°C
Seal Optional on order
LMJK8L THK Linear Bush plastic square flange long, shaft φ8mm, OD φ15mm, L=45mm, K=25mm | Shaft Dia.: D0=8mm | Outer Dia.: D=15mm | Length: L=45mm | Flange OD: D1=32mm | Square Width: K=25mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK10L THK Linear Bush plastic square flange long, shaft φ10mm, OD φ19mm, L=55mm, K=30mm | Shaft Dia.: D0=10mm | Outer Dia.: D=19mm | Length: L=55mm | Flange OD: D1=39mm | Square Width: K=30mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK12L THK Linear Bush plastic square flange long, shaft φ12mm, OD φ21mm, L=57mm, K=32mm | Shaft Dia.: D0=12mm | Outer Dia.: D=21mm | Length: L=57mm | Flange OD: D1=42mm | Square Width: K=32mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK16L THK Linear Bush plastic square flange long, shaft φ16mm, OD φ28mm, L=70mm, K=37mm | Shaft Dia.: D0=16mm | Outer Dia.: D=28mm | Length: L=70mm | Flange OD: D1=48mm | Square Width: K=37mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK20L THK Linear Bush plastic square flange long, shaft φ20mm, OD φ32mm, L=80mm, K=42mm | Shaft Dia.: D0=20mm | Outer Dia.: D=32mm | Length: L=80mm | Flange OD: D1=54mm | Square Width: K=42mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK25L THK Linear Bush plastic square flange long, shaft φ25mm, OD φ40mm, L=112mm, K=50mm | Shaft Dia.: D0=25mm | Outer Dia.: D=40mm | Length: L=112mm | Flange OD: D1=62mm | Square Width: K=50mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
Linear BushingsTHK
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK LMJK-L Linear Bush Plastic Square Flange Long Type (LMJK8L~LMJK25L)

Brand THK·Linear Bushings

Available part numbers (6)

LMJK8L, LMJK10L, LMJK12L, LMJK16L, LMJK20L, LMJK25L

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LMJK8LTHK Linear Bush plastic square flange long, shaft φ8mm, OD φ15mm, L=45mm, K=25mm | Shaft Dia.: D0=8mm | Outer Dia.: D=15mm | Length: L=45mm | Flange OD: D1=32mm | Square Width: K=25mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK10LTHK Linear Bush plastic square flange long, shaft φ10mm, OD φ19mm, L=55mm, K=30mm | Shaft Dia.: D0=10mm | Outer Dia.: D=19mm | Length: L=55mm | Flange OD: D1=39mm | Square Width: K=30mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK12LTHK Linear Bush plastic square flange long, shaft φ12mm, OD φ21mm, L=57mm, K=32mm | Shaft Dia.: D0=12mm | Outer Dia.: D=21mm | Length: L=57mm | Flange OD: D1=42mm | Square Width: K=32mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK16LTHK Linear Bush plastic square flange long, shaft φ16mm, OD φ28mm, L=70mm, K=37mm | Shaft Dia.: D0=16mm | Outer Dia.: D=28mm | Length: L=70mm | Flange OD: D1=48mm | Square Width: K=37mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK20LTHK Linear Bush plastic square flange long, shaft φ20mm, OD φ32mm, L=80mm, K=42mm | Shaft Dia.: D0=20mm | Outer Dia.: D=32mm | Length: L=80mm | Flange OD: D1=54mm | Square Width: K=42mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
LMJK25LTHK Linear Bush plastic square flange long, shaft φ25mm, OD φ40mm, L=112mm, K=50mm | Shaft Dia.: D0=25mm | Outer Dia.: D=40mm | Length: L=112mm | Flange OD: D1=62mm | Square Width: K=50mm | Flange Material: High-strength plastic (lightweight) | Type: Long type (2 retainers) | Max Temp.: 80°C | Seal: Optional on order
