• THK SKR65 LM Guide Actuator, No Cover, Motor In-line (Long Block ×1)
1 1

THK SKR65 LM Guide Actuator, No Cover, Motor In-line (Long Block ×1)

THK SKR65 LM Guide Actuator, No Cover, Motor In-line (Long Block ×1)

THK SKR65 LM Guide Actuator.

Key features

  • No cover, motor in-line (series) configuration
  • Long Block ×1 (long type)
  • Integrated LM block and ball screw nut for compact design
  • Equal load capacity in 4 directions
  • Stroke range: 790–1490 mm
  • See model number configuration guide A2-28

Specifications

Model SKR65, Long Block ×1
Cover None
Motor Mounting In-line (Series)
SKR6520A-0790 SKR65 No Cover In-line, Long Block ×1, Stroke 790mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 790 mm | Outer Rail Length: 980 mm | Overall Length L1: 1098 mm | C: 900 mm | G: 40 mm | F: 800 mm | H: 90 mm | Mounting Holes n: 7 | Sensor Rail Holes n1: 5 | Mass: 30.3 kg
SKR6520A-0990 SKR65 No Cover In-line, Long Block ×1, Stroke 990mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 990 mm | Outer Rail Length: 1180 mm | Overall Length L1: 1298 mm | C: 1050 mm | G: 65 mm | F: 1000 mm | H: 90 mm | Mounting Holes n: 8 | Sensor Rail Holes n1: 6 | Mass: 35.5 kg
SKR6520A-1190 SKR65 No Cover In-line, Long Block ×1, Stroke 1190mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 1190 mm | Outer Rail Length: 1380 mm | Overall Length L1: 1498 mm | C: 1200 mm | G: 90 mm | F: 1200 mm | H: 90 mm | Mounting Holes n: 9 | Sensor Rail Holes n1: 7 | Mass: 40.7 kg
SKR6520A-1490 SKR65 No Cover In-line, Long Block ×1, Stroke 1490mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 1490 mm | Outer Rail Length: 1680 mm | Overall Length L1: 1798 mm | C: 1500 mm | G: 90 mm | F: 1600 mm | H: 40 mm | Mounting Holes n: 11 | Sensor Rail Holes n1: 9 | Mass: 48.4 kg
LM Guide ActuatorsTHK
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

THK SKR65 LM Guide Actuator, No Cover, Motor In-line (Long Block ×1)

Brand THK·LM Guide Actuators

Available part numbers (4)

SKR6520A-0790, SKR6520A-0990, SKR6520A-1190, SKR6520A-1490

How to order

Send the THK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SKR6520A-0790SKR65 No Cover In-line, Long Block ×1, Stroke 790mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 790 mm | Outer Rail Length: 980 mm | Overall Length L1: 1098 mm | C: 900 mm | G: 40 mm | F: 800 mm | H: 90 mm | Mounting Holes n: 7 | Sensor Rail Holes n1: 5 | Mass: 30.3 kg
SKR6520A-0990SKR65 No Cover In-line, Long Block ×1, Stroke 990mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 990 mm | Outer Rail Length: 1180 mm | Overall Length L1: 1298 mm | C: 1050 mm | G: 65 mm | F: 1000 mm | H: 90 mm | Mounting Holes n: 8 | Sensor Rail Holes n1: 6 | Mass: 35.5 kg
SKR6520A-1190SKR65 No Cover In-line, Long Block ×1, Stroke 1190mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 1190 mm | Outer Rail Length: 1380 mm | Overall Length L1: 1498 mm | C: 1200 mm | G: 90 mm | F: 1200 mm | H: 90 mm | Mounting Holes n: 9 | Sensor Rail Holes n1: 7 | Mass: 40.7 kg
SKR6520A-1490SKR65 No Cover In-line, Long Block ×1, Stroke 1490mm | Model: SKR65, Long Block ×1 | Cover: None | Motor Mounting: In-line (Series) | Stroke: 1490 mm | Outer Rail Length: 1680 mm | Overall Length L1: 1798 mm | C: 1500 mm | G: 90 mm | F: 1600 mm | H: 40 mm | Mounting Holes n: 11 | Sensor Rail Holes n1: 9 | Mass: 48.4 kg
