TPC Mechatronics SL-RP E2 Self-Lubrication Unit for RP Series LM Guides (Sizes 15-45)

TPC Mechatronics SL-RP E2 Self-Lubrication Unit for RP Series LM Guides (Sizes 15-45)

The SL-RP...-E2 is an automatic self-lubrication oil box (E2 option) that mounts on the end of an RP series LM guide block.

Key features

  • It supplies lubricant to the raceways for extended maintenance-free running
  • Units are available for RP sizes 15 to 45 and fit both standard (C) and long (H) blocks; the table lists block length with and without the unit
TPC Mechatronics SL-RP E2 Self-Lubrication Unit for RP Series LM Guides (Sizes 15-45) reference 2
SL-RP15-E2 Height H: 19.5 mm | Width W: 32.6 mm | Thickness T: 15 mm | Lube port thread M: M4×0.7 | Block length L (C/H): 60.5 mm | Block length with E2 LS (C/H): 90.5 mm
SL-RP20-E2 Height H: 24.2 mm | Width W: 43 mm | Thickness T: 16 mm | Lube port thread M: M6×1 | Block length L (C/H): 76.7 / 91.4 mm | Block length with E2 LS (C/H): 108.7 / 123.4 mm
SL-RP25-E2 Height H: 29.5 mm | Width W: 47 mm | Thickness T: 17 mm | Lube port thread M: M6×1 | Block length L (C/H): 58 / 78.6 mm | Block length with E2 LS (C/H): 92 / 112.6 mm
SL-RP30-E2 Height H: 35.45 mm | Width W: 58 mm | Thickness T: 17 mm | Lube port thread M: M6×1 | Block length L (C/H): 70 / 93 mm | Block length with E2 LS (C/H): 104 / 127 mm
SL-RP35-E2 Height H: 38.9 mm | Width W: 68.8 mm | Thickness T: 20 mm | Lube port thread M: M6×1 | Block length L (C/H): 112 / 138.2 mm | Block length with E2 LS (C/H): 152 / 178.2 mm
SL-RP45-E2 Height H: 49 mm | Width W: 82.3 mm | Thickness T: 20 mm | Lube port thread M: PT 1/8 | Block length L (C/H): 137 / 169.2 mm | Block length with E2 LS (C/H): 177 / 209 mm
LM Guide AccessoriesTPC Mechatronics
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

TPC Mechatronics SL-RP E2 Self-Lubrication Unit for RP Series LM Guides (Sizes 15-45)

Brand TPC Mechatronics·LM Guide Accessories

Available part numbers (6)

SL-RP15-E2, SL-RP20-E2, SL-RP25-E2, SL-RP30-E2, SL-RP35-E2, SL-RP45-E2

How to order

Send the TPC Mechatronics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
TPC Mechatronics SL-RP E2 Self-Lubrication Unit for RP Series LM Guides (Sizes 15-45) reference 2
0 selected
RFQ List (0)
Product codeSpec
SL-RP15-E2Height H: 19.5 mm | Width W: 32.6 mm | Thickness T: 15 mm | Lube port thread M: M4×0.7 | Block length L (C/H): 60.5 mm | Block length with E2 LS (C/H): 90.5 mm
SL-RP20-E2Height H: 24.2 mm | Width W: 43 mm | Thickness T: 16 mm | Lube port thread M: M6×1 | Block length L (C/H): 76.7 / 91.4 mm | Block length with E2 LS (C/H): 108.7 / 123.4 mm
SL-RP25-E2Height H: 29.5 mm | Width W: 47 mm | Thickness T: 17 mm | Lube port thread M: M6×1 | Block length L (C/H): 58 / 78.6 mm | Block length with E2 LS (C/H): 92 / 112.6 mm
SL-RP30-E2Height H: 35.45 mm | Width W: 58 mm | Thickness T: 17 mm | Lube port thread M: M6×1 | Block length L (C/H): 70 / 93 mm | Block length with E2 LS (C/H): 104 / 127 mm
SL-RP35-E2Height H: 38.9 mm | Width W: 68.8 mm | Thickness T: 20 mm | Lube port thread M: M6×1 | Block length L (C/H): 112 / 138.2 mm | Block length with E2 LS (C/H): 152 / 178.2 mm
SL-RP45-E2Height H: 49 mm | Width W: 82.3 mm | Thickness T: 20 mm | Lube port thread M: PT 1/8 | Block length L (C/H): 137 / 169.2 mm | Block length with E2 LS (C/H): 177 / 209 mm
