WISE L200 Transparent Type Level Gauge

The WISE L200 transparent level gauge sandwiches two tempered flat glasses between front and rear covers, suiting corrosive and coloured liquids and tanks needing a long visible length. Versions are rated to 4, 18 and 24 MPa.

Key features

Front and rear tempered flat gauge glasses
Pressure ratings to 24 MPa
Top-bottom or side-side hook-up
Wide material range including LTCS and alloys
Options: non-frosting, illuminator, steam jacket, scale plate

Specifications

Max. pressure	4, 18 or 24 MPa by type
Vessel connection	1/2"-1" flanged 150/300 Lb RF, NPT, socket weld
Visible length	C to C 425 mm to over 3,925 mm (top-bottom)
Chamber material	Carbon steel, LTCS, stainless, A182 F11/22/5/9/91, Monel, titanium, Hastelloy, Alloy 20
Hook-up	Top-bottom, side-side (right/left)
Gauge valve	Straight or off-set
Drain / vent	Plug or gate, globe, ball, needle valve
Illuminator option	KCs Ex d IIC T6 IP65, ATEX II 2G Ex d IIC T6 Gb, IECEx Ex d IIC T6 Gb
Ordering options	Material, vessel connection, hook-up, gauge valve, C to C, drain/vent, options
Source	WISE data sheet LD02-01

L200

Type: Transparent | Max. pressure: 4/18/24 MPa
