WISE P111 Stainless Internal General Service Pressure Gauge

The WISE P111 has 316SS internals and is designed to withstand the shock, vibration and pulsation generated by agricultural ammonia equipment.

Key features

316SS pressure connection and bourdon tube
Compound ranges -0.1~1, 1.5, 2 MPa
Fluid temperature up to 200 °C
Accuracy ±1.5 % FS
60, 75 and 100 mm sizes

Specifications

Nominal diameter	60, 75, 100 mm
Accuracy	±1.5 % FS
Scale range	-0.1~1, -0.1~1.5, -0.1~2 MPa
Pressure connection / element	316SS, C type bourdon tube
Case / cover	Black finished steel
Window	Glass
Process connection	¼" PT; ⅜" PT and PF
Working temperature	Ambient -40 to 65 °C; fluid max. 200 °C
Working pressure	Steady 75 % FS; over range 130 % FS
Ordering options	Mounting type, connection size/type, unit, range, dial color, accessories
Source	WISE data sheet PD0-02

P111

Size: 60/75/100 mm | Accuracy: ±1.5 % FS | Range: -0.1~2 MPa
