WISE R830 General Type Stator Winding RTD

WISE R830 General Type Stator Winding RTD

WISE R830 series stator winding RTDs fit between stator and slot to detect and prevent motor overheating in general (non-hazardous) service.

Key features

  • Pt100 element in epoxy glass body
  • Class F (155 °C) or Class H (180 °C)
  • Single or double element, 3/4/6/8 wire
  • Shielded lead wire versions
  • Flexible, vibration and pressure resistant

Specifications

Element Pt100 (0.00385), Class AA / A / B to EN 60751
Body material High temperature epoxy glass
Temperature class Class F 155 °C; Class H 180 °C
Working temperature -50 to 180 °C
Body 2.0 mm thick; 6 x 155 mm (single), 11 x 155 mm (double)
Lead wires 3 or 4 wire, copper AWG 24, FEP or polyimide
Ambient temperature -50 to 180 °C
Ordering options Body length, lead wire length / colour, twisted leads
Source WISE data sheet RD08-03
R831 Element: Single | Wires: 3
R832 Element: Double | Wires: 6
R833 Element: Single | Wires: 3 | Shield: Yes
R834 Element: Double | Wires: 6 | Shield: Yes
R835 Element: Single | Wires: 4
R836 Element: Double | Wires: 8
R837 Element: Single | Wires: 4 | Shield: Yes
R838 Element: Double | Wires: 8 | Shield: Yes
Temperature Sensors (TC/RTD)WISE
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WISE R830 General Type Stator Winding RTD

Brand WISE·Temperature Sensors (TC/RTD)

Available part numbers (8)

R831, R832, R833, R834, R835, R836, R837, R838
