WISE T931, T932 Indicating Temperature Switch

Indicating temperature switch with a 150 mm dial and snap-action micro switch, suitable for measuring the temperature of corrosive fluids; fixed dead band.

Key features

150 mm indicating dial with set-point switch
Micro switch snap action, one or two SPDT
T931 case compensation; T932 full compensation
Remote bulb with armored capillary
Repeatability ±1.0 % of adjustable range

Specifications

Nominal diameter	150 mm
Measuring system	Gas; T931 -200 to 700 °C, T932 0 to 200 °C
Scale ranges	-50 to 700 °C (scale table)
Accuracy	±2.0 % FS (±1.0 % FS option)
Repeatability	±1.0 % of adjustable range
Switch	Micro switch snap action, 1 or 2 SPDT
Contacts	AC 125/250 V 15 A; DC 125 V 0.4 A resistive
Conduit connection	½", ¾" PF
Stem	8.0, 10.0, 12.0 mm; 316SS/316L SS
Process connection	⅜", ½", ¾" PT, NPT, PF
Ordering options	Switch form, stem, connection, range, capillary length, thermowell
Source	WISE data sheet TD09-02

T931		System: Case compensation (IIIB) \| Dial: 150 mm
T932		System: Full compensation (IIIA) \| Dial: 150 mm

Temperature SwitchesWISE

2 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WISE T931, T932 Indicating Temperature Switch

Brand WISE·Temperature Switches

Available part numbers (2)

T931, T932

How to order

Send the WISE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
