WISE T140 Process Industry Bimetal Thermometer, Angle Stem

Coiled bimetal thermometer for measuring the temperature of gases and liquids, built for corrosive atmospheres and demanding climatic conditions.

Key features

Center back connection with angle stem
Dial sizes 75 to 150 mm
304SS case and cover
External zero adjustment
Optional ±1.0 % FS special accuracy

Specifications

Nominal diameter	75, 100, 125, 150 mm
Stem location	Center back with angle stem
Temperature element	Coiled bimetal
Scale ranges	-50 to 600 °C (scale table)
Accuracy	±2.0 % FS (±1.0 % FS option)
Case / cover	304SS / 304SS
Stem	6.0, 6.4, 8.0, 10.0 mm; 304SS/316SS/316L SS
Insertion length	Up to 2,000 mm
Process connection	¼", ⅜", ½", ¾" PT, NPT, PF
Certificates	ATEX II 2G Ex h IIC T6…T1 Gb; ATEX II 2D Ex h IIIC T85°C…T450°C Db
Ordering options	Mounting, stem material/diameter, connection type, range, insertion length, thermowell
Source	WISE data sheet TD01-07

T140

Dial: 75, 100, 125, 150 mm | Element: Bimetal | Accuracy: ±2.0 % FS
