WISE T229 Liquid Filled Direct Reading Thermometer

Liquid-filled case gas-actuated thermometer (SAMA class IIIB) for corrosive and non-corrosive fluids; glycerin or silicone filling damps vibration while the compensated system keeps readings accurate.

Key features

Glycerin or silicone filled case for vibration damping
Direct bottom or lower back mounting
304SS case and cover
Range codes from -200 to 700 °C
Optional ±1.0 % FS special accuracy

Specifications

Nominal diameter	100, 150 mm
Stem location / mounting	Bottom or lower back, direct
Measuring system	Gas filled, SAMA class IIIB
Scale ranges	-200 to 700 °C (scale table)
Accuracy	±2.0 % FS (±1.0 % FS option)
Case / cover	304SS / 304SS
Stem	8.0, 10.0, 12.0 mm; 316SS/316L SS
Process connection	⅜", ½", ¾" PT, NPT, PF
Filling liquid	Glycerin or silicone
Certificates	ATEX II 2G Ex h IIC T6…T1 Gb; ATEX II 2D Ex h IIIC T85°C…T450°C Db
Ordering options	Mounting, stem material/diameter, connection type, range, insertion length, thermowell
Source	WISE data sheet TD02-07

T229

Dial: 100, 150 mm | Type: Direct reading | Accuracy: ±2.0 % FS
