Woonyoung B Contact (Normally Closed) Single Phase SSR WYG (15-40A)

Woonyoung B Contact (Normally Closed) Single Phase SSR WYG (15-40A)

SSR with reversed operation (output OFF when control input is ON and ON when input is OFF), single phase 15/25/40A.

Key features

  • B contact (normally closed) operation
  • 15 / 25 / 40 A
  • DC or AC control input

Specifications

Phase 1
Weight 0.1 kg
WYG1C15Z4B Contact: B (normally closed) | Rated load current: 15 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 160 A | Contact voltage drop: 1.5 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C25Z4B Contact: B (normally closed) | Rated load current: 25 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 250 A | Contact voltage drop: 1.8 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C40Z4B Contact: B (normally closed) | Rated load current: 40 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 420 A | Contact voltage drop: 1.8 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C15Z40B Contact: B (normally closed) | Rated load current: 15 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 160 A | Contact voltage drop: 1.5 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
WYG1C25Z40B Contact: B (normally closed) | Rated load current: 25 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 250 A | Contact voltage drop: 1.8 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
WYG1C40Z40B Contact: B (normally closed) | Rated load current: 40 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 420 A | Contact voltage drop: 1.8 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
Solid State RelaysWoonyoung
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung B Contact (Normally Closed) Single Phase SSR WYG (15-40A)

Brand Woonyoung·Solid State Relays

Available part numbers (6)

WYG1C15Z4B, WYG1C25Z4B, WYG1C40Z4B, WYG1C15Z40B, WYG1C25Z40B, WYG1C40Z40B

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WYG1C15Z4BContact: B (normally closed) | Rated load current: 15 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 160 A | Contact voltage drop: 1.5 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C25Z4BContact: B (normally closed) | Rated load current: 25 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 250 A | Contact voltage drop: 1.8 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C40Z4BContact: B (normally closed) | Rated load current: 40 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 420 A | Contact voltage drop: 1.8 V | Control input: DC 4-32V | Switching: Zero cross
WYG1C15Z40BContact: B (normally closed) | Rated load current: 15 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 160 A | Contact voltage drop: 1.5 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
WYG1C25Z40BContact: B (normally closed) | Rated load current: 25 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 250 A | Contact voltage drop: 1.8 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
WYG1C40Z40BContact: B (normally closed) | Rated load current: 40 A | Rated voltage: 220 VAC | Voltage range: 90-240 VAC | Peak surge current: 420 A | Contact voltage drop: 1.8 V | Control input: AC 90-240V | Switching: Zero cross | Page: 84
