Woonyoung Standard DC SSR WYNSG / WYNSH (200/500VDC, 5-40A)

Woonyoung Standard DC SSR WYNSG / WYNSH (200/500VDC, 5-40A)

Standard-type DC SSR series with CE certification and an LED that identifies the ON/OFF state according to input control.

Key features

  • DC load switching
  • 200 VDC (G) and 500 VDC (H)
  • LED status indicator
  • CE certified

Specifications

Input voltage range 4-32 VDC
Output DC
Dielectric strength 1500 VAC / 1 min
Weight 0.1 kg
WYNSG1C205D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 5 A | ON resistance: 0.4 ohm
WYNSG1C210D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 10 A | ON resistance: 0.55 ohm
WYNSG1C220D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 20 A | ON resistance: 0.085 ohm
WYNSG1C230D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 30 A | ON resistance: 0.085 ohm
WYNSG1C240D4 Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 40 A | ON resistance: 0.085 ohm
WYNSH1C505D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 5 A | ON resistance: 0.4 ohm | Page: 119
WYNSH1C510D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 10 A | ON resistance: 0.4 ohm | Page: 119
WYNSH1C520D4 Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 20 A | ON resistance: 0.3 ohm | Page: 119
Solid State RelaysWoonyoung
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung Standard DC SSR WYNSG / WYNSH (200/500VDC, 5-40A)

Brand Woonyoung·Solid State Relays

Available part numbers (8)

WYNSG1C205D4, WYNSG1C210D4, WYNSG1C220D4, WYNSG1C230D4, WYNSG1C240D4, WYNSH1C505D4, WYNSH1C510D4, WYNSH1C520D4

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WYNSG1C205D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 5 A | ON resistance: 0.4 ohm
WYNSG1C210D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 10 A | ON resistance: 0.55 ohm
WYNSG1C220D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 20 A | ON resistance: 0.085 ohm
WYNSG1C230D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 30 A | ON resistance: 0.085 ohm
WYNSG1C240D4Rated voltage: 200 VDC | Voltage range: 10-200 VDC | Rated load current: 40 A | ON resistance: 0.085 ohm
WYNSH1C505D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 5 A | ON resistance: 0.4 ohm | Page: 119
WYNSH1C510D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 10 A | ON resistance: 0.4 ohm | Page: 119
WYNSH1C520D4Rated voltage: 500 VDC | Voltage range: 10-500 VDC | Rated load current: 20 A | ON resistance: 0.3 ohm | Page: 119
