Yuken 'M' Series Electric Motor M3 (Coupling / separate housing, 5.5/7.5 kW x 4P)

Yuken 'M' Series Electric Motor M3 (Coupling / separate housing, 5.5/7.5 kW x 4P)

'M' Series Electric Motors (Type M3).

Key features

  • Coupling / separate housing mounting type for Yuken hydraulic pumps: AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane)
  • Output: 5.5/7.5 kW x 4P
  • Voltage: 50Hz AC200V / 60Hz AC200/220/230V
  • Insulation class F
  • Totally enclosed, surface-cooled (IP44 / IC411 / IEC60034-1)

Specifications

Motor Type M3
Mounting Coupling / separate housing
Insulation Class F
Enclosure Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1)
Ambient Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m
Applicable Pumps AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane)
Design No 40
M3-5.5-40 M Series motor M3, 5.5kW x 4P, Coupling / separate housing | Motor Type: M3 | Mounting: Coupling / separate housing | Output: 5.5 kW x 4P | Electrical: 200V-50Hz: 23.4A rated / 200A start / 1465rpm; 200V-60Hz: 21.4A rated / 166A start / 1760rpm; 220V-60Hz: 20.6A rated / 183A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 63 kg | Applicable Pumps: AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane) | Design No: 40
M3-7.5-40 M Series motor M3, 7.5kW x 4P, Coupling / separate housing | Motor Type: M3 | Mounting: Coupling / separate housing | Output: 7.5 kW x 4P | Electrical: 200V-50Hz: 30.8A rated / 264A start / 1460rpm; 200V-60Hz: 28.6A rated / 218A start / 1755rpm; 220V-60Hz: 27.4A rated / 240A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 74 kg | Applicable Pumps: AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane) | Design No: 40
MotorsYuken
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken 'M' Series Electric Motor M3 (Coupling / separate housing, 5.5/7.5 kW x 4P)

Brand Yuken·Motors

Available part numbers (2)

M3-5.5-40, M3-7.5-40

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
M3-5.5-40M Series motor M3, 5.5kW x 4P, Coupling / separate housing | Motor Type: M3 | Mounting: Coupling / separate housing | Output: 5.5 kW x 4P | Electrical: 200V-50Hz: 23.4A rated / 200A start / 1465rpm; 200V-60Hz: 21.4A rated / 166A start / 1760rpm; 220V-60Hz: 20.6A rated / 183A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 63 kg | Applicable Pumps: AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane) | Design No: 40
M3-7.5-40M Series motor M3, 7.5kW x 4P, Coupling / separate housing | Motor Type: M3 | Mounting: Coupling / separate housing | Output: 7.5 kW x 4P | Electrical: 200V-50Hz: 30.8A rated / 264A start / 1460rpm; 200V-60Hz: 28.6A rated / 218A start / 1755rpm; 220V-60Hz: 27.4A rated / 240A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 74 kg | Applicable Pumps: AR16/AR22/A10/A16/A22 (single), A1616/A1622/A2222 (double), A16R1/A22R1 (var/fixed double), PV2R1 (vane) | Design No: 40
