[GGM] — K22 BLDC Planetary Gearmotor KB2418R2 (Ø24.4, DC 24V, 1/4–1/1996)

Family ID: GGM-K22-2418-R2

GGM K22 Ø24.4 BLDC planetary gearmotor KB2418R2, DC 24V, 20 gear ratios from 1/4 to 1/1996. PWM speed control (GUN-type controller) with FG speed feedback (9 pulses/rev), max output torque 3 kgf·cm, output rotates same direction as motor.

20 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K22-0004-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/4, 1800 rpm / 0.06 kgf·cm (DC 24V) GGM Gear Ratio: 1/4 | Output Speed: 1800 rpm (at max. eff.) | Output Torque: 0.06 kgf·cm
K22-0014-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/14, 514 rpm / 0.2 kgf·cm (DC 24V) GGM Gear Ratio: 1/14 | Output Speed: 514 rpm (at max. eff.) | Output Torque: 0.2 kgf·cm
K22-0016-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/16, 450 rpm / 0.23 kgf·cm (DC 24V) GGM Gear Ratio: 1/16 | Output Speed: 450 rpm (at max. eff.) | Output Torque: 0.23 kgf·cm
K22-0019-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/19, 379 rpm / 0.27 kgf·cm (DC 24V) GGM Gear Ratio: 1/19 | Output Speed: 379 rpm (at max. eff.) | Output Torque: 0.27 kgf·cm
K22-0053-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/53, 136 rpm / 0.68 kgf·cm (DC 24V) GGM Gear Ratio: 1/53 | Output Speed: 136 rpm (at max. eff.) | Output Torque: 0.68 kgf·cm
K22-0062-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/62, 116 rpm / 0.8 kgf·cm (DC 24V) GGM Gear Ratio: 1/62 | Output Speed: 116 rpm (at max. eff.) | Output Torque: 0.8 kgf·cm
K22-0072-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/72, 100 rpm / 0.93 kgf·cm (DC 24V) GGM Gear Ratio: 1/72 | Output Speed: 100 rpm (at max. eff.) | Output Torque: 0.93 kgf·cm
K22-0084-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/84, 86 rpm / 1.1 kgf·cm (DC 24V) GGM Gear Ratio: 1/84 | Output Speed: 86 rpm (at max. eff.) | Output Torque: 1.1 kgf·cm
K22-0104-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/104, 69 rpm / 1.3 kgf·cm (DC 24V) GGM Gear Ratio: 1/104 | Output Speed: 69 rpm (at max. eff.) | Output Torque: 1.3 kgf·cm
K22-0198-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/198, 36 rpm / 2.3 kgf·cm (DC 24V) GGM Gear Ratio: 1/198 | Output Speed: 36 rpm (at max. eff.) | Output Torque: 2.3 kgf·cm
K22-0231-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/231, 31 rpm / 2.7 kgf·cm (DC 24V) GGM Gear Ratio: 1/231 | Output Speed: 31 rpm (at max. eff.) | Output Torque: 2.7 kgf·cm
K22-0270-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/270, 26.7 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/270 | Output Speed: 26.7 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-0316-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/316, 22.8 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/316 | Output Speed: 22.8 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-0370-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/370, 19.5 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/370 | Output Speed: 19.5 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-0455-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/455, 15.8 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/455 | Output Speed: 15.8 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-0742-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/742, 9.7 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/742 | Output Speed: 9.7 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-1014-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/1014, 7.1 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/1014 | Output Speed: 7.1 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-1249-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/1249, 5.7 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/1249 | Output Speed: 5.7 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-1621-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/1621, 4.4 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/1621 | Output Speed: 4.4 rpm (at max. eff.) | Output Torque: 3 kgf·cm
K22-1996-KB2418R2 K22 BLDC gearmotor KB2418R2, 1/1996, 3.6 rpm / 3 kgf·cm (DC 24V) GGM Gear Ratio: 1/1996 | Output Speed: 3.6 rpm (at max. eff.) | Output Torque: 3 kgf·cm
