[GGM] — K42 BLDC Planetary Gearmotor KB4932S2 (Ø49, DC 24V, 1/4–1/3600)
Family ID: GGM-K42-4932-S2
GGM K42 Ø49 BLDC planetary gearmotor KB4932S2, DC 24V with 5V logic control, 21 gear ratios from 1/4 to 1/3600. PWM speed control (GUN-type controller) with start/stop and CW/CCW, max output torque 30 kgf·cm, output rotates same direction as motor.
21 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K42-0004-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/4, 950 rpm / 1.4 kgf·cm | GGM | Gear Ratio: 1/4 | Output Speed: 950 rpm (at max. eff.) | Output Torque: 1.4 kgf·cm | ||
| K42-0014-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/14, 271 rpm / 4.4 kgf·cm | GGM | Gear Ratio: 1/14 | Output Speed: 271 rpm (at max. eff.) | Output Torque: 4.4 kgf·cm | ||
| K42-0017-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/17, 224 rpm / 5.3 kgf·cm | GGM | Gear Ratio: 1/17 | Output Speed: 224 rpm (at max. eff.) | Output Torque: 5.3 kgf·cm | ||
| K42-0024-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/24, 158 rpm / 7.5 kgf·cm | GGM | Gear Ratio: 1/24 | Output Speed: 158 rpm (at max. eff.) | Output Torque: 7.5 kgf·cm | ||
| K42-0049-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/49, 78 rpm / 14 kgf·cm | GGM | Gear Ratio: 1/49 | Output Speed: 78 rpm (at max. eff.) | Output Torque: 14 kgf·cm | ||
| K42-0061-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/61, 62 rpm / 17 kgf·cm | GGM | Gear Ratio: 1/61 | Output Speed: 62 rpm (at max. eff.) | Output Torque: 17 kgf·cm | ||
| K42-0084-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/84, 45 rpm / 24 kgf·cm | GGM | Gear Ratio: 1/84 | Output Speed: 45 rpm (at max. eff.) | Output Torque: 24 kgf·cm | ||
| K42-0104-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/104, 37 rpm / 29 kgf·cm | GGM | Gear Ratio: 1/104 | Output Speed: 37 rpm (at max. eff.) | Output Torque: 29 kgf·cm | ||
| K42-0144-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/144, 26 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/144 | Output Speed: 26 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0212-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/212, 18 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/212 | Output Speed: 18 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0263-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/263, 14 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/263 | Output Speed: 14 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0294-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/294, 13 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/294 | Output Speed: 13 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0504-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/504, 7.5 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/504 | Output Speed: 7.5 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0624-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/624, 6.1 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/624 | Output Speed: 6.1 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0720-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/720, 5.3 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/720 | Output Speed: 5.3 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-0864-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/864, 4.4 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/864 | Output Speed: 4.4 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-1062-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/1062, 3.6 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/1062 | Output Speed: 3.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-1470-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/1470, 2.6 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/1470 | Output Speed: 2.6 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-2500-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/2500, 1.52 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/2500 | Output Speed: 1.52 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-3000-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/3000, 1.26 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/3000 | Output Speed: 1.26 rpm (at max. eff.) | Output Torque: 30 kgf·cm | ||
| K42-3600-KB4932S2 | K42 BLDC gearmotor KB4932S2, 1/3600, 1.05 rpm / 30 kgf·cm | GGM | Gear Ratio: 1/3600 | Output Speed: 1.05 rpm (at max. eff.) | Output Torque: 30 kgf·cm |
