![[OMRON] — E3X-NA V-Type Water-Resistant Fiber Amplifier (IP66, M8 Connector)](https://prosourcemro.com/wp-content/uploads/2026/05/001-1.png)
Fiber Optic
Omron
[OMRON] — E3X-NA V-Type Water-Resistant Fiber Amplifier (IP66, M8 Connector)
Family ID: OMRON-E3X-NA-V-M8
Water-resistant fiber amplifier unit with IP66 protection and M8 4-pin connector for tool-free cable replacement and quick maintenance. Ideal for wet processing, food and beverage production, and equipment requiring frequent disconnect. Bar display with 8-turn adjuster. 12-24 VDC, open-collector output (NPN/PNP). Compatible with E32 series fiber optic head units. Sensor I/O cable XS3F-M421-402-A / XS3F-M421-405-A (straight) or XS3F-M422-402-A / XS3F-M422-405-A (L-shaped) sold separately. Mounting Bracket (E39-L148) and DIN track End Plate (PFP-M) sold separately.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E3X-NA14V | OMRON E3X-NA14V water-resistant fiber amplifier, NPN, IP66, M8 connector. | OMRON | Output: NPN | Connection: M8 4-pin connector (XS3F cable sold separately) | Light Source: Red LED (680 nm) | Display: 5-segment bar (4 green + 1 red) excess gain indicator | Sensitivity Setting: 8-turn sensitivity adjuster (with indicator) | Power Supply: 12 to 24 VDC ±10%, ripple (p-p) 10% max. | Power Consumption: 840 mW max. (35 mA @ 24 VDC) | Control Output: Open-collector, 26.4 V max., 50 mA max., residual voltage 1 V max. | Mode Selector: Light-ON / Dark-ON | Response Time: Operate/Reset 200 μs max. | Timer Function: No timer / OFF-delay (40 ms fixed) — selectable | Mutual Interference Prevention: Up to 5 amplifiers (optically synchronized) | Protection: IP66 ⭐ Water-resistant | Ambient Temperature: -25°C to 55°C (1-3 amps), -25°C to 50°C (4-11), -25°C to 45°C (12-16) | Connector: M8 4-pin (XS3F-M421/M422 cable sold separately) | Mounting: DIN track or Mounting Bracket E39-L148 (sold separately) | ||
| E3X-NA44V | OMRON E3X-NA44V water-resistant fiber amplifier, PNP, IP66, M8 connector. | OMRON | Output: PNP | Connection: M8 4-pin connector (XS3F cable sold separately) | Light Source: Red LED (680 nm) | Display: 5-segment bar (4 green + 1 red) excess gain indicator | Sensitivity Setting: 8-turn sensitivity adjuster (with indicator) | Power Supply: 12 to 24 VDC ±10%, ripple (p-p) 10% max. | Power Consumption: 840 mW max. (35 mA @ 24 VDC) | Control Output: Open-collector, 26.4 V max., 50 mA max., residual voltage 1 V max. | Mode Selector: Light-ON / Dark-ON | Response Time: Operate/Reset 200 μs max. | Timer Function: No timer / OFF-delay (40 ms fixed) — selectable | Mutual Interference Prevention: Up to 5 amplifiers (optically synchronized) | Protection: IP66 ⭐ Water-resistant | Ambient Temperature: -25°C to 55°C (1-3 amps), -25°C to 50°C (4-11), -25°C to 45°C (12-16) | Connector: M8 4-pin (XS3F-M421/M422 cable sold separately) | Mounting: DIN track or Mounting Bracket E39-L148 (sold separately) |
