![[OMRON] — E6C3-A Absolute Rotary Encoder (Gray, NPN, H8PS Connector, 12~24VDC)](https://prosourcemro.com/wp-content/uploads/2026/05/001-415-1024x683.png)
Rotary Encoder
Omron
[OMRON] — E6C3-A Absolute Rotary Encoder (Gray, NPN, H8PS Connector, 12~24VDC)
Family ID: OMRON-E6C3A-GRAY-NPN-C
OMRON E6C3-A 50mm absolute encoder. Gray code, NPN, H8PS Cam Positioner connector. 256/360/720 P/R. Pre-wired connector 1m.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6C3-AG5C-C 256P/R 1M | E6C3-A Gray NPN conn 256P/R 1m | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: NPN open-collector | Code: Gray | Resolution: 256P/R | Connection: Pre-wired Connector 1 m | Note: For H8PS Cam Positioner. | ||
| E6C3-AG5C-C 360P/R 1M | E6C3-A Gray NPN conn 360P/R 1m | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: NPN open-collector | Code: Gray | Resolution: 360P/R | Connection: Pre-wired Connector 1 m | Note: For H8PS Cam Positioner. 2m also available | ||
| E6C3-AG5C-C 720P/R 1M | E6C3-A Gray NPN conn 720P/R 1m | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: NPN open-collector | Code: Gray | Resolution: 720P/R | Connection: Pre-wired Connector 1 m | Note: For H8PS Cam Positioner. 2m standard stock; only 2m for H8PS |
