Rotary Encoder
Omron
[OMRON] — E6D-C High-resolution Rotary Encoder (Open-collector Output, 12VDC, 1000~6000P/R)
Family ID: OMRON-E6D-OC
OMRON E6D-C Series 55mm high-resolution incremental rotary encoder. Open-collector output. 12 VDC. 1,000/2,000/3,600/5,000/6,000 P/R. A/B/Z phases. Cable 0.5m. Additional resolutions available on request.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6D-CWZ2C 1,000P/R 0.5M | E6D-C OC 12V 1,000P/R 0.5m | OMRON | Output Type: Open-collector output | Power Supply: 12 VDC | Resolution: 1,000P/R | Output Phases: A, B, Z | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 55 mm | Note: Additional resolutions available on request: 720/800/1,024/1,200/1,500/1,800/2,048/2,500/3,000/3,200/4,096 P/R | ||
| E6D-CWZ2C 2,000P/R 0.5M | E6D-C OC 12V 2,000P/R 0.5m | OMRON | Output Type: Open-collector output | Power Supply: 12 VDC | Resolution: 2,000P/R | Output Phases: A, B, Z | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 55 mm | Note: Additional resolutions available on request: 720/800/1,024/1,200/1,500/1,800/2,048/2,500/3,000/3,200/4,096 P/R | ||
| E6D-CWZ2C 3,600P/R 0.5M | E6D-C OC 12V 3,600P/R 0.5m | OMRON | Output Type: Open-collector output | Power Supply: 12 VDC | Resolution: 3,600P/R | Output Phases: A, B, Z | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 55 mm | Note: Additional resolutions available on request: 720/800/1,024/1,200/1,500/1,800/2,048/2,500/3,000/3,200/4,096 P/R | ||
| E6D-CWZ2C 5,000P/R 0.5M | E6D-C OC 12V 5,000P/R 0.5m | OMRON | Output Type: Open-collector output | Power Supply: 12 VDC | Resolution: 5,000P/R | Output Phases: A, B, Z | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 55 mm | Note: Additional resolutions available on request: 720/800/1,024/1,200/1,500/1,800/2,048/2,500/3,000/3,200/4,096 P/R | ||
| E6D-CWZ2C 6,000P/R 0.5M | E6D-C OC 12V 6,000P/R 0.5m | OMRON | Output Type: Open-collector output | Power Supply: 12 VDC | Resolution: 6,000P/R | Output Phases: A, B, Z | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 55 mm | Note: Additional resolutions available on request: 720/800/1,024/1,200/1,500/1,800/2,048/2,500/3,000/3,200/4,096 P/R |
