[OMRON] — G3NA Solid State Relay (Hockey-puck, 5-90A, 240/480VAC+DC, UL/CSA/TÜV)
Relays Omron

[OMRON] — G3NA Solid State Relay (Hockey-puck, 5-90A, 240/480VAC+DC, UL/CSA/TÜV)

Family ID: OMRON-G3NA

The reliable choice for Hockey-puck-style Solid State Relays. Available in a Wide Range of Currents.

41 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
G3NA-205B-UTU DC5-24 G3NA 5A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 5A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-205B-UTU AC100-240 G3NA 5A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 5A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-210B-UTU DC5-24 G3NA 10A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 10A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-210B-UTU AC100-240 G3NA 10A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 10A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-220B-UTU DC5-24 G3NA 20A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 20A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-220B-UTU AC100-240 G3NA 20A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 20A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-225B-UTU DC5-24 G3NA 25A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 25A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-225B-UTU AC100-240 G3NA 25A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 25A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-240B-UTU DC5-24 G3NA 40A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 40A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-240B-UTU AC100-240 G3NA 40A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 40A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-250B-UTU DC5-24 G3NA 50A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 50A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-250B-UTU AC100-240 G3NA 50A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 50A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-275B-UTU-2 DC5-24 G3NA 75A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 75A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-275B-UTU-2 AC100-240 G3NA 75A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 75A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-290B-UTU-2 DC5-24 G3NA 90A 24-240VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 90A / 24-240 VAC | Input: 5-24 VDC | Isolation: Phototriac | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-290B-UTU-2 AC100-240 G3NA 90A 24-240VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 90A / 24-240 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Indicator: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-410B-UTU DC5-24 G3NA 10A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 10A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-410B-UTU AC100-240 G3NA 10A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 10A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-420B-UTU DC5-24 G3NA 20A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 20A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-420B-UTU AC100-240 G3NA 20A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 20A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-425B-UTU-2 DC5-24 G3NA 25A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 25A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-425B-UTU-2 AC100-240 G3NA 25A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 25A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-440B-UTU-2 DC5-24 G3NA 40A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 40A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-440B-UTU-2 AC100-240 G3NA 40A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 40A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-450B-UTU-2 DC5-24 G3NA 50A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 50A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-450B-UTU-2 AC100-240 G3NA 50A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 50A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-475B-UTU-2 DC5-24 G3NA 75A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 75A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-475B-UTU-2 AC100-240 G3NA 75A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 75A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-490B-UTU-2 DC5-24 G3NA 90A 200-480VAC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck) | Load: 90A / 200-480 VAC | Input: 5-24 VDC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-490B-UTU-2 AC100-240 G3NA 90A 200-480VAC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck) | Load: 90A / 200-480 VAC | Input: 100-240 VAC | Isolation: Photocoupler | Zero Cross: Yes | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-D210B-UTU DC5-24 G3NA 10A 5-200VDC 5-24 VDC OMRON Type: G3NA SSR (Hockey-puck, DC load) | Load: 10A / 5-200 VDC | Input: 5-24 VDC | Zero Cross: --- | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
G3NA-D210B-UTU AC100-240 G3NA 10A 5-200VDC 100-240 VAC OMRON Type: G3NA SSR (Hockey-puck, DC load) | Load: 10A / 5-200 VDC | Input: 100-240 VAC | Zero Cross: --- | Note: Load current depends on ambient temperature and heat sink. UL/CSA/TÜV certified.
R99-12 FOR G3NA G3NA One-touch Mounting Plate OMRON Type: G3NA Mounting Plate
Y92B-N50 G3NA Heat Sink DIN Y92B-N50 OMRON Type: G3NA Heat Sink (DIN Track) | Applicable: G3NA-205B/210B/D210B/410B
Y92B-N100 G3NA Heat Sink DIN Y92B-N100 OMRON Type: G3NA Heat Sink (DIN Track) | Applicable: G3NA-220B/420B
Y92B-N150 G3NA Heat Sink DIN Y92B-N150 OMRON Type: G3NA Heat Sink (DIN Track) | Applicable: G3NA-225B/240B/425B/440B
Y92B-P250 G3NA Heat Sink DIN Y92B-P250 OMRON Type: G3NA Heat Sink (DIN Track) | Applicable: G3NA-250B/450B
Y92B-P250NF G3NA Heat Sink DIN Y92B-P250NF OMRON Type: G3NA Heat Sink (DIN Track) | Applicable: G3NA-275B/290B/475B/490B
Y92B-A100 G3NA Heat Sink Screw Y92B-A100 OMRON Type: G3NA Heat Sink (Screw) | Applicable: G3NA-205B/210B/D210B/220B/410B/420B
Y92B-A150N G3NA Heat Sink Screw Y92B-A150N OMRON Type: G3NA Heat Sink (Screw) | Applicable: G3NA-225B/240B/425B/440B
Y92B-A250 G3NA Heat Sink Screw Y92B-A250 OMRON Type: G3NA Heat Sink (Screw) | Applicable: G3NA-440B
