![[OMRON] — H3DS Solid-state Timer (17.5mm DIN Track, Multi-mode/Twin/Star-delta/ON-delay, Screw or Screwless)](https://img.prosourcemro.com/2026/05/001-636-1024x683.png)
Timer
Omron
[OMRON] — H3DS Solid-state Timer (17.5mm DIN Track, Multi-mode/Twin/Star-delta/ON-delay, Screw or Screwless)
Family ID: OMRON-H3DS
DIN Track Mounted, Standard 17.5mm Width Timer Range. H3DS-M: 8-mode (A/B/B2/C/D/E/G/J, voltage input). H3DS-S: 4-mode (A/B2/E/J, no-input). H3DS-A: Single mode ON-delay. H3DS-F: Flicker OFF/ON start. H3DS-G: Star-delta. H3DS-X: ON-delay (wide voltage). Screw terminal and Screwless clamp variants. Supply: 24~230VAC/24~48VDC.
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| H3DS-ML | 8-mode Timer (A/B/B2/C/D/E/G/J), Voltage input, SPDT, Screw terminal, 24~230VAC/24~48VDC | OMRON | Type: Eight-mode Timer | Modes: A/B/B2/C/D/E/G/J | Input: Voltage | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-SL | 4-mode Timer (A/B2/E/J), No-input, SPDT, Screw terminal, 24~230VAC/24~48VDC | OMRON | Type: Four-mode Timer | Modes: A/B2/E/J | Input: No-input | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-AL | Single-mode ON-delay Timer, No-input, SPDT, Screw terminal, 24~230VAC/24~48VDC | OMRON | Type: Single-mode Timer | Mode: A (ON-delay) | Input: No-input | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-MLC | 8-mode Timer (A/B/B2/C/D/E/G/J), Voltage input, SPDT, Screwless clamp, 24~230VAC/24~48VDC | OMRON | Type: Eight-mode Timer | Modes: A/B/B2/C/D/E/G/J | Input: Voltage | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-SLC | 4-mode Timer (A/B2/E/J), No-input, SPDT, Screwless clamp, 24~230VAC/24~48VDC | OMRON | Type: Four-mode Timer | Modes: A/B2/E/J | Input: No-input | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-ALC | Single-mode ON-delay Timer, No-input, SPDT, Screwless clamp, 24~230VAC/24~48VDC | OMRON | Type: Single-mode Timer | Mode: A (ON-delay) | Input: No-input | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-FL | Twin Timer, Flicker OFF/ON start, SPDT, Screw terminal, 24~230VAC/24~48VDC | OMRON | Type: Twin Timer | Mode: Flicker OFF/ON start | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-FLC | Twin Timer, Flicker OFF/ON start, SPDT, Screwless clamp, 24~230VAC/24~48VDC | OMRON | Type: Twin Timer | Mode: Flicker OFF/ON start | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-GL | Star-delta Timer, SPDT, Screw terminal, 24~230VAC/24~48VDC | OMRON | Type: Star-delta Timer | Mode: Star-delta | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-GLC | Star-delta Timer, SPDT, Screwless clamp, 24~230VAC/24~48VDC | OMRON | Type: Star-delta Timer | Mode: Star-delta | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC (50/60Hz) / 24~48VDC | Mounting: DIN Track 17.5mm | ||
| H3DS-XL | ON-delay Timer, No-input, SPDT, Screw terminal, 24~230VAC/VDC | OMRON | Type: ON-delay Timer | Mode: ON-delay | Input: No-input | Output: SPDT | Terminal: Screw | Supply Voltage: 24~230VAC/VDC (50/60Hz) | Mounting: DIN Track 17.5mm | ||
| H3DS-XLC | ON-delay Timer, No-input, SPDT, Screwless clamp, 24~230VAC/VDC | OMRON | Type: ON-delay Timer | Mode: ON-delay | Input: No-input | Output: SPDT | Terminal: Screwless Clamp | Supply Voltage: 24~230VAC/VDC (50/60Hz) | Mounting: DIN Track 17.5mm |
