Timer
Omron
[OMRON] — H3DK-H Power OFF-delay Timer (22.5mm DIN Track, S/L Series, SPDT, 24~48VAC/DC or 100~240VAC)
Family ID: OMRON-H3DK-H
DIN Track-mounted, 22.5mm-width Standard Timer Series. Power OFF Delay. S-series: 0.1~12s. L-series: 1.0~120s. SPDT relay output. 6 terminals. Instantaneous operation / time-limit reset. Supply voltage: 100~120VAC / 200~240VAC / 24~48VAC/DC.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| H3DK-HCS | Power OFF-delay, S Series (0.1~12s), SPDT, 100~120VAC | OMRON | Type: Power OFF-delay Timer | Series: S (0.1~12s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 100~120VAC | Mounting: DIN Track 22.5mm | ||
| H3DK-HCL | Power OFF-delay, L Series (1.0~120s), SPDT, 100~120VAC | OMRON | Type: Power OFF-delay Timer | Series: L (1.0~120s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 100~120VAC | Mounting: DIN Track 22.5mm | ||
| H3DK-HDS | Power OFF-delay, S Series (0.1~12s), SPDT, 200~240VAC | OMRON | Type: Power OFF-delay Timer | Series: S (0.1~12s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 200~240VAC | Mounting: DIN Track 22.5mm | ||
| H3DK-HDL | Power OFF-delay, L Series (1.0~120s), SPDT, 200~240VAC | OMRON | Type: Power OFF-delay Timer | Series: L (1.0~120s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 200~240VAC | Mounting: DIN Track 22.5mm | ||
| H3DK-HBS | Power OFF-delay, S Series (0.1~12s), SPDT, 24~48VAC/DC | OMRON | Type: Power OFF-delay Timer | Series: S (0.1~12s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 24~48VAC/DC | Mounting: DIN Track 22.5mm | ||
| H3DK-HBL | Power OFF-delay, L Series (1.0~120s), SPDT, 24~48VAC/DC | OMRON | Type: Power OFF-delay Timer | Series: L (1.0~120s) | Output: Relay SPDT | Terminals: 6 | Supply Voltage: 24~48VAC/DC | Mounting: DIN Track 22.5mm |
