[OSG] — 688206K Coated End Mill

Family ID: 311-3509

OSG 688206K Coated End Mill is a coated carbide cutting tool designed for precision milling operations, sourced direct from Korea. End mills of this type are commonly used in CNC machining centers to profile, slot, and contour ferrous and non-ferrous workpieces across metalworking and tooling applications. Request a quote today for export-ready supply with competitive pricing, fulfilled through a KITA-registered Korean exporter.

44 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
311-3509 688206K OSG 4F-3MM(TICN-EMS)(688206K) | Spec: 3 | Flute Length: 10(10) | Overall Length: 55(50) | Product Name: 4-Flute Coating | Shank Diameter: 6
311-3518 688207K OSG 4F-3.5MM (TICN-EMS)(688207K) | Spec: 3.5 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3527 688208K OSG 4F-4MM(TICN-EMS)(688208K) | Spec: 4 | Flute Length: 12 | Overall Length: 60 | Product Name: Coated 4F | Shank Diameter: 8
311-3536 688209K OSG 4F-4.5MM(TICN-EMS)(688209K) | Spec: 4.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3545 688210K OSG 4F-5MM(TICN-EMS)(688210K) | Spec: 5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3554 688211K OSG 4F-5.5MM (TICN-EMS)(688211K) | Spec: 5.5 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3563 688212K OSG 4F-6MM(TICN-EMS)(688212K) | Spec: 6 | Flute Length: 15 | Overall Length: 65(60) | Product Name: Coated 4F | Shank Diameter: 8
311-3572 688213K OSG 4F-6.5MM (TICN-EMS)(688213K) | Spec: 6.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coating 4F | Shank Diameter: 10
311-3581 688215K OSG 4F-7.5MM (TICN-EMS)(688215K) | Spec: 7.5 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3590 688214K OSG 4F-7MM(TICN-EMS)(688214K) | Spec: 7 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3606 688217K OSG 4F-8.5MM (TICN-EMS)(688217K) | Spec: 8.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3615 688216K OSG 4F-8MM(TICN-EMS)(688216K) | Spec: 8 | Flute Length: 20 | Overall Length: 75(60) | Product Name: Coated 4F | Shank Diameter: 10
311-3624 688219K OSG 4F-9.5MM (TICN-EMS)(688219K) | Spec: 9.5 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coating 4F | Shank d: 10
311-3633 688218K OSG 4F-9MM(TICN-EMS)(688218K) | Spec: 9 | Flute Length: 25 | Overall Length: 80(70) | Product Name: Coated 4F | Shank Diameter: 10
311-3642 688220K OSG 4F-10MM(TICN-EMS)(688220K) | Spec: 10 | Flute Length: 25 | Overall Length: 80(70) | Type: Coated 4F | Shank d: 10
311-3651 688221K OSG 4F-11MM(TICN-EMS)(688221K) | Spec: 11 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3660 688222K OSG 4F-12MM(TICN-EMS)(688222K) | Spec: 12 | Flute Length: 30 | Overall Length: 90(80) | Product Name: Coated 4F | Shank Diameter: 12
311-3679 688223K OSG 4F-13MM(TICN-EMS)(688223K) | Spec: 13 | Flute Length: 35 | Overall Length: 95(85) | Product Name: Coated 4F | Shank Diameter: 12
311-3688 688224K OSG 4F-14MM(TICN-EMS)(688224K) | Spec: 14 | Flute Length: 35 | Overall Length: 100(90) | Description: Coated 4F | Shank Diameter: 16
311-3697 688225K OSG 4F-15MM(TICN-EMS)(688225K) | Spec: 15 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3703 688226K OSG 4F-16MM(TICN-EMS)(688226K) | Spec: 16 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coating 4F | Shank d: 16
311-3712 688227K OSG 4F-17MM(TICN-EMS)(688227K) | Spec: 17 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3721 688228K OSG 4F-18MM(TICN-EMS)(688228K) | Spec: 18 | Flute Length: 40 | Overall Length: 105(95) | Product Name: Coated 4F | Shank Diameter: 16
311-3730 688229K OSG 4F-19MM (TICN-EMS)(688229K) | Spec: 19 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3749 688230K OSG 4F-20MM(TICN-EMS)(688230K) | Spec: 20 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3758 688231K OSG 4F-21MM(TICN-EMS)(688231K) | Spec: 21 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank Diameter: 20
311-3767 688232K OSG 4F-22MM(TICN-EMS)(688232K) | Spec: 22 | Flute Length: 45 | Overall Length: 115(110) | Product Name: Coated 4F | Shank d: 20
311-3776 688233K OSG 4F-23MM(TICN-EMS)(688233K) | Spec: 23 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coating 4F | Shank d: 25
311-3785 688234K OSG 4F-24MM(TICN-EMS)(688234K) | Spec: 24 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3794 688235K OSG 4F-25MM (TICN-EMS)(688235K) | Spec: 25 | Flute Length: 50 | Overall Length: 125(120) | Product Name: Coated 4F | Shank Diameter: 25
311-3800 688236K OSG 4F-26MM (TICN-EMS)(688236K) | Spec: 26 | Flute Length: 50 | Overall Length: 125(120) | Description: Coated 4-Flute | Shank Diameter: 25
311-3819 688237K OSG 4F-27MM (TICN-EMS)(688237K) | Spec: 27 | Flute Length: 55 | Overall Length: 125 | Product Name: Coating 4F | Shank d: 25
311-3828 688238K OSG 4F-28MM (TICN-EMS)(688238K) | Spec: 28 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3846 688240K OSG 4F-30MM (TICN-EMS)(688240K) | Spec: 30 | Flute Length: 55 | Overall Length: 125 | Product Name: Coated 4F | Shank Diameter: 25
311-3855 688242K OSG 4F-32MM (TICN-EMS)(688242K) | Spec: 32 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
311-3873 688250K OSG 4F-40MM(TICN-EMS)(688250K) | Spec: 40 | Flute Length: 65 | Overall Length: 150 | Description: Coated 4-Flute | Shank Diameter: 32
313-8012 688205K OSG 4F-2.5MM(TICN-EMS)(688205K) | Spec: 2.5 | Flute Length: 7(10) | Overall Length: 55(50) | Product Name: Coated 4F | Shank Diameter: 6
313-8049 688243K OSG 4F-33MM(TICN-EMS)(688243K) | Spec: 33 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8216 688245K OSG 4F-35MM(TiCN-EMS)(688245K) | Spec: 35 | Flute Length: 60 | Overall Length: 145 | Product Name: Coated 4F | Shank Diameter: 32
313-8225 688246K OSG 4F-36MM(TICN-EMS)(688246K) | Spec: 36 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8234 688247K OSG 4F-37MM(TICN-EMS)(688247K) | Spec: 37 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank Diameter: 32
313-8243 688248K OSG 4F-38MM(TICN-EMS)(688248K) | Spec: 38 | Flute Length: 65 | Overall Length: 150 | Product: Coated 4F | Shank Diameter: 32
313-8252 688249K OSG 4F-39MM(TICN-EMS)(688249K) | Spec: 39 | Flute Length: 65 | Overall Length: 150 | Product Name: Coated 4F | Shank d: 32
313-8368 688203K OSG 4F-2MM(TICN-EMS)(688203K) | Spec: 2 | Flute Length: 6 | Overall Length: 55 | Product Name: Coated 4F | Shank Diameter: 6
