Yuken — 005 Series Throttle & Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-005-THRCHK
005 Series Modular Valves — Throttle & Check. Sandwich/stack mounting. Detailed specifications by inquiry.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MSA-005-X-20 | Throttle-and-check modular valve 005, A-line, meter-out | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (A-line, meter-out) | Control Code: X | ||
| MSA-005-Y-20 | Throttle-and-check modular valve 005, A-line, meter-in | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (A-line, meter-in) | Control Code: Y | ||
| MSB-005-X-20 | Throttle-and-check modular valve 005, B-line, meter-out | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (B-line, meter-out) | Control Code: X | ||
| MSB-005-Y-20 | Throttle-and-check modular valve 005, B-line, meter-in | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (B-line, meter-in) | Control Code: Y | ||
| MSW-005-X-20 | Throttle-and-check modular valve 005, A & B line, meter-out | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (A & B line, meter-out) | Control Code: X | ||
| MSW-005-Y-20 | Throttle-and-check modular valve 005, A & B line, meter-in | Yuken | Series: 005 Modular | Max Pressure: 25 MPa | Max Flow: 15 L/min | Mounting: Sandwich/stack (005 - non-ISO 4401) | Function: Throttle & check (A & B line, meter-in) | Control Code: Y |
