Flow Control Modular
Yuken
Yuken — 03 Series Pressure-Compensated Flow Control Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-FLOWCTRL
03 Series Modular Valves — Pressure-Compensated Flow Control. Sandwich/stack mounting. Detailed specifications by inquiry.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MFP-03-11 | Flow control modular valve 03, P-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pressure-compensated flow control (P-line) | ||
| MFA-03-X-11 | Flow control & check modular valve 03, A-line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (A-line, meter-out) | Control Code: X | ||
| MFA-03-Y-11 | Flow control & check modular valve 03, A-line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (A-line, meter-in) | Control Code: Y | ||
| MFB-03-X-11 | Flow control & check modular valve 03, B-line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (B-line, meter-out) | Control Code: X | ||
| MFB-03-Y-11 | Flow control & check modular valve 03, B-line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (B-line, meter-in) | Control Code: Y | ||
| MFW-03-X-11 | Flow control & check modular valve 03, A & B line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (A & B line, meter-out) | Control Code: X | ||
| MFW-03-Y-11 | Flow control & check modular valve 03, A & B line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Flow control + check (A & B line, meter-in) | Control Code: Y |
