Yuken — 01 Series Temperature-Compensated Throttle & Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-TEMPTHRCHK
01 Series Modular Valves — Temperature-Compensated Throttle & Check. Sandwich/stack mounting. Detailed specifications by inquiry.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MSTA-01-X-10 | Temp-comp throttle-and-check modular valve 01, A-line, meter-out | Yuken | Series: 01 Modular (1/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Temp-comp throttle & check (A-line, meter-out) | Control Code: X | ||
| MSTB-01-X-10 | Temp-comp throttle-and-check modular valve 01, B-line, meter-out | Yuken | Series: 01 Modular (1/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Temp-comp throttle & check (B-line, meter-out) | Control Code: X | ||
| MSTW-01-X-10 | Temp-comp throttle-and-check modular valve 01, A & B line, meter-out | Yuken | Series: 01 Modular (1/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Temp-comp throttle & check (A & B line, meter-out) | Control Code: X |
