Flow Control Modular
Yuken
Yuken — 03 Series Throttle & Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-THRCHK
03 Series Modular Valves — Throttle & Check. Sandwich/stack mounting. Detailed specifications by inquiry.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MSA-03-X-70 | Throttle-and-check modular valve 03, A-line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-out) | Control Code: X | ||
| MSA-03-Y-70 | Throttle-and-check modular valve 03, A-line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A-line, meter-in) | Control Code: Y | ||
| MSB-03-X-70 | Throttle-and-check modular valve 03, B-line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-out) | Control Code: X | ||
| MSB-03-Y-70 | Throttle-and-check modular valve 03, B-line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (B-line, meter-in) | Control Code: Y | ||
| MSW-03-X-70 | Throttle-and-check modular valve 03, A & B line, meter-out | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-out) | Control Code: X | ||
| MSW-03-Y-70 | Throttle-and-check modular valve 03, A & B line, meter-in | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Throttle & check (A & B line, meter-in) | Control Code: Y |
