Yuken — 01 Series Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-01-CHECK
01 Series Modular Valves — Check. Sandwich/stack mounting. Detailed specifications by inquiry.
15 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MCP-01-0-70 | Check modular valve, P-line, cracking 0.035 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCP-01-2-70 | Check modular valve, P-line, cracking 0.2 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCP-01-4-70 | Check modular valve, P-line, cracking 0.4 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCA-01-0-70 | Check modular valve, A-line, cracking 0.035 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCA-01-2-70 | Check modular valve, A-line, cracking 0.2 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCA-01-4-70 | Check modular valve, A-line, cracking 0.4 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCB-01-0-70 | Check modular valve, B-line, cracking 0.035 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (B-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCB-01-2-70 | Check modular valve, B-line, cracking 0.2 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (B-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCB-01-4-70 | Check modular valve, B-line, cracking 0.4 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (B-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCT-01-0-70 | Check modular valve, T-line, cracking 0.035 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCT-01-2-70 | Check modular valve, T-line, cracking 0.2 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCT-01-4-70 | Check modular valve, T-line, cracking 0.4 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCW-01-0-70 | Check modular valve, A·B-line, cracking 0.035 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A·B-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCW-01-2-70 | Check modular valve, A·B-line, cracking 0.2 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A·B-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min | ||
| MCW-01-4-70 | Check modular valve, A·B-line, cracking 0.4 MPa | Yuken | Series: 01 (1/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (A·B-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 60 L/min |
