Yuken — 03 Series Check (P & T Line) Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-CHECKPT
03 Series Modular Valves — Check (P & T Line). Sandwich/stack mounting. Detailed specifications by inquiry.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MCPT-03-P*-T*-10 | Check modular valve 03, P & T line (dual) | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P & T line, dual) | ||
| MCPT-03-P0-T0-10 | Check modular valve (P & T line), P-crack 0.035 MPa / T-crack 0.035 MPa | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P & T line) | P-line Cracking: P0: 0.035 MPa | T-line Cracking: T0: 0.035 MPa | Max Pressure: 25 MPa | Max Flow: 70 L/min | ||
| MCPT-03-P0-T2-10 | Check modular valve (P & T line), P-crack 0.035 MPa / T-crack 0.2 MPa | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P & T line) | P-line Cracking: P0: 0.035 MPa | T-line Cracking: T2: 0.2 MPa | Max Pressure: 25 MPa | Max Flow: 70 L/min | ||
| MCPT-03-P2-T0-10 | Check modular valve (P & T line), P-crack 0.2 MPa / T-crack 0.035 MPa | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P & T line) | P-line Cracking: P2: 0.2 MPa | T-line Cracking: T0: 0.035 MPa | Max Pressure: 25 MPa | Max Flow: 70 L/min | ||
| MCPT-03-P2-T2-10 | Check modular valve (P & T line), P-crack 0.2 MPa / T-crack 0.2 MPa | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P & T line) | P-line Cracking: P2: 0.2 MPa | T-line Cracking: T2: 0.2 MPa | Max Pressure: 25 MPa | Max Flow: 70 L/min |
