Yuken — 03 Series Pilot Operated Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-03-PILOTCHECK
03 Series Modular Valves — Pilot Operated Check. Sandwich/stack mounting. Detailed specifications by inquiry.
21 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MPA-03-*-*-70 | Pilot operated check modular valve 03, A-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | ||
| MPB-03-*-*-70 | Pilot operated check modular valve 03, B-line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | ||
| MPW-03-*-*-70 | Pilot operated check modular valve 03, A & B line | Yuken | Series: 03 Modular (3/8) | Max Pressure: 35 MPa | Max Flow: per module - RFQ | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A & B line) | ||
| MPA-03-0-70 | Pilot operated check modular valve, A-line, cracking 0.035 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPA-03-0-L-70 | Pilot operated check modular valve, A-line, cracking 0.035 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPA-03-2-70 | Pilot operated check modular valve, A-line, cracking 0.2 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPA-03-2-L-70 | Pilot operated check modular valve, A-line, cracking 0.2 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPA-03-4-70 | Pilot operated check modular valve, A-line, cracking 0.4 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPA-03-4-L-70 | Pilot operated check modular valve, A-line, cracking 0.4 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-0-70 | Pilot operated check modular valve, B-line, cracking 0.035 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-0-L-70 | Pilot operated check modular valve, B-line, cracking 0.035 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-2-70 | Pilot operated check modular valve, B-line, cracking 0.2 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-2-L-70 | Pilot operated check modular valve, B-line, cracking 0.2 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-4-70 | Pilot operated check modular valve, B-line, cracking 0.4 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPB-03-4-L-70 | Pilot operated check modular valve, B-line, cracking 0.4 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-0-70 | Pilot operated check modular valve, A·B-line, cracking 0.035 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-0-L-70 | Pilot operated check modular valve, A·B-line, cracking 0.035 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 0: 0.035 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-2-70 | Pilot operated check modular valve, A·B-line, cracking 0.2 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-2-L-70 | Pilot operated check modular valve, A·B-line, cracking 0.2 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-4-70 | Pilot operated check modular valve, A·B-line, cracking 0.4 MPa, standard pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Standard pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min | ||
| MPW-03-4-L-70 | Pilot operated check modular valve, A·B-line, cracking 0.4 MPa, low pilot | Yuken | Series: 03 (3/8) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot Type: Low pilot | Max Pressure: 35 MPa | Max Flow: 120 L/min |
