Yuken — 10 Series Pilot Operated Check Modular Valve (Sandwich Type)
Directional & Check Modular Yuken

Yuken — 10 Series Pilot Operated Check Modular Valve (Sandwich Type)

Family ID: YUK-FMOD-10-PILOTCHECK

10 (1¼) Series Pilot Operated Check Modular Valves. Sandwich/stack mounting (ISO 4401). A/B/A·B-line, cracking 2/4, internal/external pilot & drain variants. Max 25 MPa / 800 L/min.

22 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
MPA-10-2-30 Pilot operated check modular valve, A-line, cracking 0.2 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10-4-30 Pilot operated check modular valve, A-line, cracking 0.4 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10-2-X-30 Pilot operated check modular valve, A-line, cracking 0.2 MPa, external pilot · external drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · external drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10-4-X-30 Pilot operated check modular valve, A-line, cracking 0.4 MPa, external pilot · external drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · external drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10S-2-X-30 Pilot operated check modular valve, A-line, cracking 0.2 MPa, external pilot · external drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · external drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10S-4-X-30 Pilot operated check modular valve, A-line, cracking 0.4 MPa, external pilot · external drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · external drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10-2-Y-30 Pilot operated check modular valve, A-line, cracking 0.2 MPa, external pilot · internal drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10-4-Y-30 Pilot operated check modular valve, A-line, cracking 0.4 MPa, external pilot · internal drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10S-2-Y-30 Pilot operated check modular valve, A-line, cracking 0.2 MPa, external pilot · internal drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPA-10S-4-Y-30 Pilot operated check modular valve, A-line, cracking 0.4 MPa, external pilot · internal drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-2-30 Pilot operated check modular valve, B-line, cracking 0.2 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-4-30 Pilot operated check modular valve, B-line, cracking 0.4 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-2-X-30 Pilot operated check modular valve, B-line, cracking 0.2 MPa, external pilot · external drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · external drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-4-X-30 Pilot operated check modular valve, B-line, cracking 0.4 MPa, external pilot · external drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · external drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10S-2-X-30 Pilot operated check modular valve, B-line, cracking 0.2 MPa, external pilot · external drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · external drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10S-4-X-30 Pilot operated check modular valve, B-line, cracking 0.4 MPa, external pilot · external drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · external drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-2-Y-30 Pilot operated check modular valve, B-line, cracking 0.2 MPa, external pilot · internal drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10-4-Y-30 Pilot operated check modular valve, B-line, cracking 0.4 MPa, external pilot · internal drain, Rc 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: none: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10S-2-Y-30 Pilot operated check modular valve, B-line, cracking 0.2 MPa, external pilot · internal drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPB-10S-4-Y-30 Pilot operated check modular valve, B-line, cracking 0.4 MPa, external pilot · internal drain, G 3/8 Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: External pilot · internal drain | Port Thread: S: G 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPW-10-2-30 Pilot operated check modular valve, A·B-line, cracking 0.2 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 2: 0.2 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
MPW-10-4-30 Pilot operated check modular valve, A·B-line, cracking 0.4 MPa, internal pilot/internal drain Yuken Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 4: 0.4 MPa | Pilot/Drain: Internal pilot · internal drain | Port Thread: Rc 3/8 | Max Pressure: 25 MPa | Max Flow: 800 L/min
