Yuken — 04 Series Pilot Operated Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-04-PILOTCHECK
04 Series Modular Valves — Pilot Operated Check. Sandwich/stack mounting. Detailed specifications by inquiry.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MPA-04-2-10 | Pilot operated check modular valve, A-line, cracking 0.2 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MPA-04-4-10 | Pilot operated check modular valve, A-line, cracking 0.4 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MPB-04-2-10 | Pilot operated check modular valve, B-line, cracking 0.2 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MPB-04-4-10 | Pilot operated check modular valve, B-line, cracking 0.4 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (B-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MPW-04-2-10 | Pilot operated check modular valve, A·B-line, cracking 0.2 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MPW-04-4-10 | Pilot operated check modular valve, A·B-line, cracking 0.4 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Pilot operated check (A·B-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min |
