Yuken — 04 Series Check Modular Valve (Sandwich Type)
Family ID: YUK-FMOD-04-CHECK
04 Series Modular Valves — Check. Sandwich/stack mounting. Detailed specifications by inquiry.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MCP-04-0-10 | Check modular valve, P-line, cracking 0.035 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MCP-04-2-10 | Check modular valve, P-line, cracking 0.2 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MCP-04-4-10 | Check modular valve, P-line, cracking 0.4 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (P-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MCT-04-0-10 | Check modular valve, T-line, cracking 0.035 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 0: 0.035 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MCT-04-2-10 | Check modular valve, T-line, cracking 0.2 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 2: 0.2 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min | ||
| MCT-04-4-10 | Check modular valve, T-line, cracking 0.4 MPa | Yuken | Series: 04 (1/2) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Check (T-line) | Cracking Pressure: 4: 0.4 MPa | Max Pressure: 35 MPa | Max Flow: 300 L/min |
