[Yuken] — AME-D2-1010 Power Amplifier for 10Ω-10Ω Power-Saving Valves
Family ID: YK-AME-D2-1010
Yuken dual-channel DC-input power amplifier for 10Ω-10Ω power-saving valves. It can drive two 10Ω solenoids simultaneously or individually for combined pressure and flow control; the front-panel controls are marked PRESS and FLOW but the two circuits are identical, so either may be used. Drives the EFBG power-saving (relief-built-in flow control) valves and the other 10Ω-series valves (EDG/EBG/ERBG/EFG/EFCG[51]), and also the A-series proportional load-sensing variable piston pumps. Max output current 1 A (10Ω solenoid), max command input DC +10 V, input impedance 10 kΩ, max gain 1 A/5 V, variable dither 100–300 mA, temperature drift 0.2 mA/°C. Common AC100V/200V supply (50/60 Hz), 120 VA, mass 4.3 kg.
1 product code available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AME-D2-1010-11 | Yuken AME-D2-1010-11 dual-channel power amplifier for 10ohm-10ohm power-saving valves | Yuken | Type: Dual-channel power amplifier for 10Ω-10Ω power-saving valves (pressure + flow) | Brand: Yuken | Model: AME-D2-1010-11 | Function: D2 (DC input, pressure & flow control) | Load: 1010 (10Ω × 2) | Max Output Current: 1 A (10Ω solenoid) | Max Command Input: DC +10 V | Input Impedance: 10 kΩ | Max Gain: 1 A / 5 V | Dither: variable 100–300 mA | Temp Drift: 0.2 mA/°C | Power Supply: AC 100 V/200 V common (50/60 Hz) | Power Consumption: 120 VA | External Setter: 1 kΩ | Mass: 4.3 kg | Drives: EFBG power-saving valves; 10Ω valves; A-series load-sensing piston pumps | Design No.: 11 |
