[Yuken] — SK1115 Power Amplifier for High-Performance Power-Saving Valve (ELFBG-03)
Family ID: YK-SK1115
Yuken DC-input power amplifier for the high-performance proportional power-saving valve ELFBG-03. Provides LVDT spool-position feedback, a slope (ramp) function and an alarm output for stable, high-accuracy flow control. The compensation code (1 or 2) is matched to the valve flow rating (1 = ELFBG-03-125, 2 = ELFBG-03-170). Max output current 2.5 A, command input 0 to +10 V, input impedance ≥10 kΩ, sensor-monitor output -0.5 V/1 mm stroke, alarm output max DC30V/10 mA. Supply DC24V (20–30 V incl. ripple), mass 0.3 kg. No power switch (operates as soon as powered — fit an external switch).
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| SK1115-1-20 | Yuken SK1115-1-20 power amplifier for ELFBG-03 high-performance power-saving valve (For ELFBG-03-125) | Yuken | Type: Power amplifier for high-performance power-saving valve (ELFBG-03) | Brand: Yuken | Model: SK1115-1-20 | Compensation: 1 (For ELFBG-03-125) | Function: DC input type | Max Output Current: 2.5 A | Command Input: 0 to +10 V | Input Impedance: ≥10 kΩ | Feedback: LVDT (spool position) | Slope Function: Yes | Sensor Monitor Output: -0.5 V / 1 mm stroke | Alarm Output: max DC30V / 10 mA | Power Supply: DC24V (20–30 V incl. ripple) | Mass: 0.3 kg | Drives: ELFBG-03 high-performance power-saving valve | Design No.: 20 | ||
| SK1115-2-20 | Yuken SK1115-2-20 power amplifier for ELFBG-03 high-performance power-saving valve (For ELFBG-03-170) | Yuken | Type: Power amplifier for high-performance power-saving valve (ELFBG-03) | Brand: Yuken | Model: SK1115-2-20 | Compensation: 2 (For ELFBG-03-170) | Function: DC input type | Max Output Current: 2.5 A | Command Input: 0 to +10 V | Input Impedance: ≥10 kΩ | Feedback: LVDT (spool position) | Slope Function: Yes | Sensor Monitor Output: -0.5 V / 1 mm stroke | Alarm Output: max DC30V / 10 mA | Power Supply: DC24V (20–30 V incl. ripple) | Mass: 0.3 kg | Drives: ELFBG-03 high-performance power-saving valve | Design No.: 20 |
