[Yuken] — Power Amplifiers for 10Ω Series Proportional Control Valves
Family ID: YK-AMP-10OHM
Yuken dedicated power amplifiers that drive the proportional solenoids of 10Ω-series proportional electro-hydraulic control valves (e.g. EDG pilot relief, EBG relief, ERBG relieving/reducing), converting a command signal into a proportional solenoid drive current. Available as AC-powered rack types (AME-D-10, SK1022-A/B with command-feedback) and a compact DC24V lead-wire type (SK1015). The full order code carries a valve-matching option (※) specified per matched valve.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AME-D-10 | Yuken AME-D-10 power amplifier for 10ohm proportional control valves, AC 100/200 V, Rack type | Yuken | Type: Power amplifier for 10Ω proportional control valves | Brand: Yuken | Model: AME-D-10 | Order Code: AME-D-10-※-20 (※ = valve-matching option, specify per valve / RFQ) | Power Supply: AC 100/200 V | Form: Rack type | Features: Manual-setter (MC-01) compatible, MAX/zero/dither adjustment, output-current meter; +12V internal supply | Dimensions: 80 × 199 × 185.5 mm | Drives: 10Ω proportional control valves (EDG / EBG / ERBG) | ||
| SK1022-A | Yuken SK1022-A power amplifier for 10ohm proportional control valves, AC 100/200/220 V, Rack type (feedback) | Yuken | Type: Power amplifier for 10Ω proportional control valves | Brand: Yuken | Model: SK1022-A | Order Code: SK1022-A-※-11 (※ = valve-matching option, specify per valve / RFQ) | Power Supply: AC 100/200/220 V | Form: Rack type (feedback) | Features: Feedback type (REF/F.B), gain/null/dither and reference/input-ratio adjustment, output-current meter | Dimensions: 125 × 199 × 260 mm | Drives: 10Ω proportional control valves (EDG / EBG / ERBG) | ||
| SK1022-B | Yuken SK1022-B power amplifier for 10ohm proportional control valves, AC 100/200/220 V, Rack type (feedback) | Yuken | Type: Power amplifier for 10Ω proportional control valves | Brand: Yuken | Model: SK1022-B | Order Code: SK1022-B-※-11 (※ = valve-matching option, specify per valve / RFQ) | Power Supply: AC 100/200/220 V | Form: Rack type (feedback) | Features: Feedback type (REF/F.B), gain/null/dither and reference/input-ratio adjustment, output-current meter | Dimensions: 125 × 199 × 260 mm | Drives: 10Ω proportional control valves (EDG / EBG / ERBG) | ||
| SK1015 | Yuken SK1015 power amplifier for 10ohm proportional control valves, DC 24 V, Compact lead-wire type | Yuken | Type: Power amplifier for 10Ω proportional control valves | Brand: Yuken | Model: SK1015 | Order Code: SK1015-11 (※ = valve-matching option, specify per valve / RFQ) | Power Supply: DC 24 V | Form: Compact lead-wire type | Features: Compact lead-wire amplifier, zero/gain adjustment; no power switch (operates as soon as power applied — fit external switch). Setter potentiometer 10 kΩ | Dimensions: 120 × 85 × 45 mm | Drives: 10Ω proportional control valves (EDG / EBG / ERBG) |
