[Yuken] — EFBG-10 10Ω-10Ω Proportional Power-Saving Valve (E series, 24.5 MPa, max 500 L/min, size 10)
Family ID: YK-EFBG-10
10Ω-10Ω Series Proportional Electro-Hydraulic Flow Control and Relief Valves. E-series energy-saving valve that supplies only the minimum pressure and flow needed to drive the actuator: it controls pump pressure with a very small differential against the load pressure, so power consumption is low; a temperature-compensated meter-in flow-adjusting valve giving stable flow control regardless of oil temperature. Use with a dedicated Yuken power amplifier. Sub-plate mounting, valve size 10. Max operating pressure 24.5 MPa, max flow 500 L/min (5–500 L/min). Pilot-relief pressure range C: 1.5–15.7 MPa / H: 1.5–24.5 MPa; or no pilot relief valve (safety valve built-in). Internal/external pilot. Coil 10Ω.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EFBG-10-500-C-51 | EFBG-10 Power-Saving (E), 500L/min, pilot relief C, Internal pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 | ||
| EFBG-10-500-C-E-51 | EFBG-10 Power-Saving (E), 500L/min, pilot relief C, External pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: C (1.5–15.7 MPa), rated current 800 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 | ||
| EFBG-10-500-H-51 | EFBG-10 Power-Saving (E), 500L/min, pilot relief H, Internal pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 | ||
| EFBG-10-500-H-E-51 | EFBG-10 Power-Saving (E), 500L/min, pilot relief H, External pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief Pressure: H (1.5–24.5 MPa), rated current 900 mA | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 | ||
| EFBG-10-500-51 | EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), Internal pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: Internal pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 | ||
| EFBG-10-500-E-51 | EFBG-10 Power-Saving (E), 500L/min, no pilot relief valve (safety valve built-in), External pilot | Yuken | Type: Proportional Power-Saving Valve (Flow Control + Relief, E series, current-driven) | Series: EFBG (10Ω-10Ω) | Mounting: Sub-plate (G) | Valve Size: 10 | Max Adjustable Flow: 500 L/min | Flow Adj. Range: 5–500 L/min | Max Pressure: 24.5 MPa | Pilot Relief: None (safety valve built-in), max adjustment pressure 24.5 MPa | Pilot: External pilot | Flow-control Rated Current: 900 mA | Valve Pressure Drop: 0.9 MPa | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Design No.: 51 |
