[Yuken] — EHFBG-03-250 High-Flow Proportional Power-Saving Valve (24.5 MPa, max 250 L/min)
Family ID: YK-EHFBG-HF-03
High Flow Series Proportional Electro-Hydraulic Flow Control and Relief Valves. High-flow version of the EHFBG power-saving valve with roughly double the max flow of the standard series (03: 125→250, 06: 250→500 L/min) and a one-step smaller valve size for a more compact installation. Supplies only the minimum pressure and flow needed to drive the actuator, with temperature-compensated meter-in flow control. Sub-plate mounting, valve size 03. Max operating pressure 24.5 MPa, max flow 250 L/min. Pilot-relief pressure range C: 1.6–15.7 MPa / H: 1.8–24.5 MPa. With/without pilot relief, internal/external flow pilot, optional pressure sensor. Coil 10Ω, DC24V (28W max).
10 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EHFBG-03-250-50 | EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), Internal pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: Internal pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-E-50 | EHFBG-03-250 High-Flow Power-Saving, no pilot relief valve (flow control only), External pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: None (no pilot relief valve) | Flow-control Pilot: External pilot | Pressure-control: None | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-C-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, Internal pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-C-E-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop, External pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-C-S-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, Internal pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-C-E-S-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief C, open loop + sensor, External pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range C (1.6–15.7 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-H-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, Internal pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-H-E-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop, External pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-H-S-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, Internal pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: Internal pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFBG-03-250-H-E-S-50 | EHFBG-03-250 High-Flow Power-Saving, pilot relief H, open loop + sensor, External pilot | Yuken | Type: High-Flow Proportional Power-Saving Valve (Flow Control + Relief) | Series: EHFBG (High Flow) | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 250 L/min | Flow Adj. Range: 2.5–250 L/min | Pilot Relief Pressure: Range H (1.8–24.5 MPa) | Flow-control Pilot: External pilot | Pressure-control: Open loop + built-in sensor | Valve Pressure Drop: 0.8 MPa | Max Pressure: 24.5 MPa | Coil: 10Ω, DC24V | Design No.: 50 |
