[YUKEN] — LSVG-03 Direct Type High-Speed Linear Servo Valve
Family ID: YK-LSVG03
Direct type high-speed linear servo valve using a compact, powerful linear motor as the actuator, with the moving coil, spool, and position sensor combined in series for a very simple structure. Hysteresis 0.1% or less; step response 2 ms (size 60: 3 ms); frequency response −3 dB gain up to 350 Hz. Excellent vibration resistance from the simple construction and superior contamination tolerance, usable to NAS 1638 class 10 (ISO4406 21/19/15). Max operating pressure 35 MPa. Neutral zero-lap spool. Requires dedicated AMLS linear servo amplifier.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| LSVG-03-4-10 | LSVG-03 Direct Linear Servo Valve, 4 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 4 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | ||
| LSVG-03-10-10 | LSVG-03 Direct Linear Servo Valve, 10 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 10 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | ||
| LSVG-03-20-10 | LSVG-03 Direct Linear Servo Valve, 20 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 20 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | ||
| LSVG-03-40-10 | LSVG-03 Direct Linear Servo Valve, 40 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 40 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 2 ms (3) | Frequency Resp. (−3 dB gain): 350 Hz (300) | Frequency Resp. (−90° phase): 450 Hz (370) | Spool Rated Stroke: ±0.5 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-A-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 | ||
| LSVG-03-60-10 | LSVG-03 Direct Linear Servo Valve, 60 L/min (ΔP=7MPa) | YUKEN | Type: Direct (single-stage), neutral zero-lap | Valve Size: 03 (ISO 4401-05) | Rated Flow (ΔP=7MPa): 60 L/min | Max Operating Pressure: 35 MPa | Tank Port Pressure: 35 MPa | Drain Port Y Back Pressure: 0.05 MPa max | Hysteresis: 0.1% max | Step Response (0↔100%): 3 ms (4) | Frequency Resp. (−3 dB gain): 330 Hz (240) | Frequency Resp. (−90° phase): 410 Hz (330) | Spool Rated Stroke: ±0.75 mm | Linear Motor: 2 A (6 A max), coil 4.5 Ω @20°C | Internal Leakage (Ps=14MPa, 32mm²/s): 1.7 L/min max | Protection: IP64 | Ambient Temp: −15 to +60 °C | Mass: 5 kg | Mounting Bolts: M8×65L ×4, 30.8–37.7 N·m (M6 spec on request) | Dedicated Amplifier: AMLS-B-D48/D24 | Cable Port Direction: Top (standard) / R (right) / L (left) — select per order | Fluid: Mineral oil (standard) / Phosphate-ester (F prefix, fluoro rubber seals) | Source: Yuken Cat. I-Edit0, I-5/I-6 |
