CKD 4F Master Valve Air-Piloted 5-Port (4F4-4F7, Sub-Plate)

CKD 4F Master Valve Air-Piloted 5-Port (4F4-4F7, Sub-Plate)

CKD 4F4-4F7 series air-piloted 5-port master valves with sub-plate piping, supplied as single valves or M4F common-exhaust manifolds of 2 to 10 stations.

Key features

  • Air-operated pilot soft spool valve for large cylinders (bore up to 250 mm); pilot port Rc1/8
  • All five switching types on every size: 2-position single/double, 3-position closed, A-B-R and P-A-B connection
  • Sub-plate ports: 4F4 Rc1/4-3/8, 4F5 Rc3/8-1/2, 4F6 Rc1/2-3/4, 4F7 Rc3/4-1; flow C up to 18 dm3/(s.bar) (4F6), S 160 mm2 (4F7)
  • Manifold port codes 08 (4F4), 10 (4F5), D15 (4F6), E20 (4F7), common exhaust (C)
  • Options ordered as suffix (not listed): P mounting bracket, N plug, H check valve (3-pos closed), NC/NO 3-port plug assembly; mix manifold by spec sheet

Specifications

Valve type Air-piloted soft spool valve (master)
Fluid Compressed air
Max. operating pressure 1.0 MPa
Main pressure 0.15-1.0 MPa (2-pos single), 0-1.0 MPa others
Pilot signal pressure >=0.6 x main +0.06 (single); >=0.15 (double); >=0.2 MPa (3-pos)
Ambient temperature -10 to 60 C (no freezing)
Fluid temperature 5 to 60 C
Lubrication Not required (turbine oil ISO VG32 if used)
Vibration / shock 50 m/s2 or less / 300 m/s2 or less
Source CKD Korea catalog CB-023SK-9, p. 1530-1539
4F411-08 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/4 | Stations: 1
4F411-10 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/8 | Stations: 1
4F421-08 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/4 | Stations: 1
4F421-10 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/8 | Stations: 1
4F431-08 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 1
4F431-10 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 1
4F441-08 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 1
4F441-10 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 1
4F451-08 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 1
4F451-10 Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 1
4F511-10 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/8 | Stations: 1
4F511-15 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/2 | Stations: 1
4F521-10 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/8 | Stations: 1
4F521-15 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/2 | Stations: 1
4F531-10 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 1
4F531-15 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 1
4F541-10 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 1
4F541-15 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 1
4F551-10 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 1
4F551-15 Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 1
4F611-15 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/2 | Stations: 1
4F611-20 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/4 | Stations: 1
4F621-15 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/2 | Stations: 1
4F621-20 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/4 | Stations: 1
4F631-15 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 1
4F631-20 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 1
4F641-15 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 1
4F641-20 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 1
4F651-15 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 1
4F651-20 Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 1
4F711-20 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/4 | Stations: 1
4F711-25 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1 | Stations: 1
4F721-20 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/4 | Stations: 1
4F721-25 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1 | Stations: 1
4F731-20 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 1
4F731-25 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1 | Stations: 1
4F741-20 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 1
4F741-25 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1 | Stations: 1
4F751-20 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 1
4F751-25 Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1 | Stations: 1
M4F411-08-2-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 2
M4F411-08-3-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 3
M4F411-08-4-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 4
M4F411-08-5-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 5
M4F411-08-6-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 6
M4F411-08-7-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 7
M4F411-08-8-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 8
M4F411-08-9-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 9
M4F411-08-10-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 10
M4F421-08-2-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 2
M4F421-08-3-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 3
M4F421-08-4-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 4
M4F421-08-5-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 5
M4F421-08-6-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 6
M4F421-08-7-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 7
M4F421-08-8-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 8
M4F421-08-9-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 9
M4F421-08-10-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 10
M4F431-08-2-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 2
M4F431-08-3-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 3
M4F431-08-4-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 4
M4F431-08-5-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 5
M4F431-08-6-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 6
M4F431-08-7-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 7
M4F431-08-8-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 8
M4F431-08-9-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 9
M4F431-08-10-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 10
M4F441-08-2-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 2
M4F441-08-3-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 3
M4F441-08-4-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 4
M4F441-08-5-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 5
M4F441-08-6-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 6
M4F441-08-7-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 7
M4F441-08-8-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 8
M4F441-08-9-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 9
M4F441-08-10-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 10
M4F451-08-2-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 2
M4F451-08-3-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 3
M4F451-08-4-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 4
M4F451-08-5-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 5
M4F451-08-6-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 6
M4F451-08-7-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 7
M4F451-08-8-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 8
M4F451-08-9-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 9
M4F451-08-10-C Model: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 10
M4F511-10-2-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 2
M4F511-10-3-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 3
M4F511-10-4-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 4
M4F511-10-5-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 5
M4F511-10-6-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 6
M4F511-10-7-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 7
M4F511-10-8-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 8
M4F511-10-9-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 9
M4F511-10-10-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 10
M4F521-10-2-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 2
M4F521-10-3-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 3
M4F521-10-4-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 4
M4F521-10-5-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 5
M4F521-10-6-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 6
M4F521-10-7-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 7
M4F521-10-8-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 8
M4F521-10-9-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 9
M4F521-10-10-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 10
M4F531-10-2-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 2
M4F531-10-3-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 3
M4F531-10-4-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 4
M4F531-10-5-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 5
M4F531-10-6-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 6
M4F531-10-7-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 7
M4F531-10-8-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 8
M4F531-10-9-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 9
M4F531-10-10-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 10
M4F541-10-2-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 2
M4F541-10-3-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 3
M4F541-10-4-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 4
M4F541-10-5-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 5
M4F541-10-6-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 6
M4F541-10-7-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 7
M4F541-10-8-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 8
M4F541-10-9-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 9
M4F541-10-10-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 10
M4F551-10-2-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 2
M4F551-10-3-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 3
M4F551-10-4-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 4
M4F551-10-5-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 5
M4F551-10-6-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 6
M4F551-10-7-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 7
M4F551-10-8-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 8
M4F551-10-9-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 9
M4F551-10-10-C Model: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 10
M4F611-D15-2-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 2
M4F611-D15-3-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 3
M4F611-D15-4-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 4
M4F611-D15-5-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 5
M4F611-D15-6-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 6
M4F611-D15-7-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 7
M4F611-D15-8-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 8
M4F611-D15-9-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 9
M4F611-D15-10-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 10
M4F621-D15-2-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 2
M4F621-D15-3-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 3
M4F621-D15-4-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 4
M4F621-D15-5-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 5
M4F621-D15-6-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 6
M4F621-D15-7-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 7
M4F621-D15-8-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 8
M4F621-D15-9-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 9
M4F621-D15-10-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 10
M4F631-D15-2-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 2
M4F631-D15-3-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 3
M4F631-D15-4-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 4
M4F631-D15-5-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 5
M4F631-D15-6-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 6
M4F631-D15-7-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 7
M4F631-D15-8-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 8
M4F631-D15-9-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 9
M4F631-D15-10-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 10
M4F641-D15-2-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 2
M4F641-D15-3-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 3
M4F641-D15-4-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 4
M4F641-D15-5-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 5
M4F641-D15-6-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 6
M4F641-D15-7-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 7
M4F641-D15-8-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 8
M4F641-D15-9-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 9
M4F641-D15-10-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 10
M4F651-D15-2-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 2
M4F651-D15-3-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 3
M4F651-D15-4-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 4
M4F651-D15-5-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 5
M4F651-D15-6-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 6
M4F651-D15-7-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 7
M4F651-D15-8-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 8
M4F651-D15-9-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 9
M4F651-D15-10-C Model: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 10
M4F711-E20-2-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 2
M4F711-E20-3-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 3
M4F711-E20-4-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 4
M4F711-E20-5-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 5
M4F711-E20-6-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 6
M4F711-E20-7-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 7
M4F711-E20-8-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 8
M4F711-E20-9-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 9
M4F711-E20-10-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 10
M4F721-E20-2-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 2
M4F721-E20-3-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 3
M4F721-E20-4-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 4
M4F721-E20-5-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 5
M4F721-E20-6-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 6
M4F721-E20-7-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 7
M4F721-E20-8-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 8
M4F721-E20-9-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 9
M4F721-E20-10-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 10
M4F731-E20-2-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 2
M4F731-E20-3-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 3
M4F731-E20-4-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 4
M4F731-E20-5-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 5
M4F731-E20-6-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 6
M4F731-E20-7-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 7
M4F731-E20-8-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 8
M4F731-E20-9-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 9
M4F731-E20-10-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 10
M4F741-E20-2-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 2
M4F741-E20-3-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 3
M4F741-E20-4-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 4
M4F741-E20-5-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 5
M4F741-E20-6-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 6
M4F741-E20-7-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 7
M4F741-E20-8-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 8
M4F741-E20-9-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 9
M4F741-E20-10-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 10
M4F751-E20-2-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 2
M4F751-E20-3-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 3
M4F751-E20-4-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 4
M4F751-E20-5-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 5
M4F751-E20-6-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 6
M4F751-E20-7-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 7
M4F751-E20-8-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 8
M4F751-E20-9-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 9
M4F751-E20-10-C Model: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 10
Pneumatic ValvesCKD
220 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD 4F Master Valve Air-Piloted 5-Port (4F4-4F7, Sub-Plate)

Brand CKD·Pneumatic Valves

Available part numbers (220)

4F411-08, 4F411-10, 4F421-08, 4F421-10, 4F431-08, 4F431-10, 4F441-08, 4F441-10, 4F451-08, 4F451-10 + 210 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
4F411-08Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/4 | Stations: 1
4F411-10Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/8 | Stations: 1
4F421-08Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/4 | Stations: 1
4F421-10Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/8 | Stations: 1
4F431-08Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 1
4F431-10Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 1
4F441-08Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 1
4F441-10Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 1
4F451-08Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 1
4F451-10Model: 4F4 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 1
4F511-10Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/8 | Stations: 1
4F511-15Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/2 | Stations: 1
4F521-10Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/8 | Stations: 1
4F521-15Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/2 | Stations: 1
4F531-10Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 1
4F531-15Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 1
4F541-10Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 1
4F541-15Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 1
4F551-10Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 1
4F551-15Model: 4F5 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 1
4F611-15Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1/2 | Stations: 1
4F611-20Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/4 | Stations: 1
4F621-15Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1/2 | Stations: 1
4F621-20Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/4 | Stations: 1
4F631-15Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 1
4F631-20Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 1
4F641-15Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 1
4F641-20Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 1
4F651-15Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 1
4F651-20Model: 4F6 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 1
4F711-20Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc3/4 | Stations: 1
4F711-25Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos single | Port size: Rc1 | Stations: 1
4F721-20Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc3/4 | Stations: 1
4F721-25Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 2-pos double | Port size: Rc1 | Stations: 1
4F731-20Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 1
4F731-25Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos all ports closed | Port size: Rc1 | Stations: 1
4F741-20Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 1
4F741-25Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos A-B-R connection | Port size: Rc1 | Stations: 1
4F751-20Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 1
4F751-25Model: 4F7 | Mounting: Single valve (sub-plate) | Switching: 3-pos P-A-B connection | Port size: Rc1 | Stations: 1
M4F411-08-2-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 2
M4F411-08-3-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 3
M4F411-08-4-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 4
M4F411-08-5-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 5
M4F411-08-6-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 6
M4F411-08-7-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 7
M4F411-08-8-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 8
M4F411-08-9-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 9
M4F411-08-10-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/4 | Stations: 10
M4F421-08-2-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 2
M4F421-08-3-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 3
M4F421-08-4-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 4
M4F421-08-5-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 5
M4F421-08-6-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 6
M4F421-08-7-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 7
M4F421-08-8-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 8
M4F421-08-9-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 9
M4F421-08-10-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/4 | Stations: 10
M4F431-08-2-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 2
M4F431-08-3-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 3
M4F431-08-4-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 4
M4F431-08-5-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 5
M4F431-08-6-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 6
M4F431-08-7-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 7
M4F431-08-8-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 8
M4F431-08-9-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 9
M4F431-08-10-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/4 | Stations: 10
M4F441-08-2-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 2
M4F441-08-3-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 3
M4F441-08-4-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 4
M4F441-08-5-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 5
M4F441-08-6-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 6
M4F441-08-7-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 7
M4F441-08-8-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 8
M4F441-08-9-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 9
M4F441-08-10-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/4 | Stations: 10
M4F451-08-2-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 2
M4F451-08-3-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 3
M4F451-08-4-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 4
M4F451-08-5-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 5
M4F451-08-6-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 6
M4F451-08-7-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 7
M4F451-08-8-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 8
M4F451-08-9-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 9
M4F451-08-10-CModel: 4F4 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/4 | Stations: 10
M4F511-10-2-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 2
M4F511-10-3-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 3
M4F511-10-4-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 4
M4F511-10-5-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 5
M4F511-10-6-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 6
M4F511-10-7-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 7
M4F511-10-8-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 8
M4F511-10-9-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 9
M4F511-10-10-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/8 | Stations: 10
M4F521-10-2-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 2
M4F521-10-3-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 3
M4F521-10-4-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 4
M4F521-10-5-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 5
M4F521-10-6-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 6
M4F521-10-7-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 7
M4F521-10-8-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 8
M4F521-10-9-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 9
M4F521-10-10-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/8 | Stations: 10
M4F531-10-2-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 2
M4F531-10-3-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 3
M4F531-10-4-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 4
M4F531-10-5-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 5
M4F531-10-6-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 6
M4F531-10-7-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 7
M4F531-10-8-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 8
M4F531-10-9-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 9
M4F531-10-10-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/8 | Stations: 10
M4F541-10-2-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 2
M4F541-10-3-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 3
M4F541-10-4-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 4
M4F541-10-5-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 5
M4F541-10-6-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 6
M4F541-10-7-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 7
M4F541-10-8-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 8
M4F541-10-9-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 9
M4F541-10-10-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/8 | Stations: 10
M4F551-10-2-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 2
M4F551-10-3-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 3
M4F551-10-4-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 4
M4F551-10-5-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 5
M4F551-10-6-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 6
M4F551-10-7-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 7
M4F551-10-8-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 8
M4F551-10-9-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 9
M4F551-10-10-CModel: 4F5 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/8 | Stations: 10
M4F611-D15-2-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 2
M4F611-D15-3-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 3
M4F611-D15-4-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 4
M4F611-D15-5-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 5
M4F611-D15-6-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 6
M4F611-D15-7-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 7
M4F611-D15-8-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 8
M4F611-D15-9-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 9
M4F611-D15-10-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc1/2 | Stations: 10
M4F621-D15-2-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 2
M4F621-D15-3-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 3
M4F621-D15-4-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 4
M4F621-D15-5-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 5
M4F621-D15-6-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 6
M4F621-D15-7-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 7
M4F621-D15-8-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 8
M4F621-D15-9-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 9
M4F621-D15-10-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc1/2 | Stations: 10
M4F631-D15-2-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 2
M4F631-D15-3-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 3
M4F631-D15-4-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 4
M4F631-D15-5-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 5
M4F631-D15-6-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 6
M4F631-D15-7-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 7
M4F631-D15-8-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 8
M4F631-D15-9-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 9
M4F631-D15-10-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc1/2 | Stations: 10
M4F641-D15-2-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 2
M4F641-D15-3-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 3
M4F641-D15-4-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 4
M4F641-D15-5-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 5
M4F641-D15-6-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 6
M4F641-D15-7-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 7
M4F641-D15-8-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 8
M4F641-D15-9-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 9
M4F641-D15-10-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc1/2 | Stations: 10
M4F651-D15-2-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 2
M4F651-D15-3-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 3
M4F651-D15-4-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 4
M4F651-D15-5-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 5
M4F651-D15-6-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 6
M4F651-D15-7-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 7
M4F651-D15-8-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 8
M4F651-D15-9-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 9
M4F651-D15-10-CModel: 4F6 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc1/2 | Stations: 10
M4F711-E20-2-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 2
M4F711-E20-3-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 3
M4F711-E20-4-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 4
M4F711-E20-5-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 5
M4F711-E20-6-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 6
M4F711-E20-7-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 7
M4F711-E20-8-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 8
M4F711-E20-9-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 9
M4F711-E20-10-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos single | Port size: Rc3/4 | Stations: 10
M4F721-E20-2-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 2
M4F721-E20-3-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 3
M4F721-E20-4-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 4
M4F721-E20-5-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 5
M4F721-E20-6-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 6
M4F721-E20-7-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 7
M4F721-E20-8-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 8
M4F721-E20-9-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 9
M4F721-E20-10-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 2-pos double | Port size: Rc3/4 | Stations: 10
M4F731-E20-2-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 2
M4F731-E20-3-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 3
M4F731-E20-4-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 4
M4F731-E20-5-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 5
M4F731-E20-6-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 6
M4F731-E20-7-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 7
M4F731-E20-8-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 8
M4F731-E20-9-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 9
M4F731-E20-10-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos all ports closed | Port size: Rc3/4 | Stations: 10
M4F741-E20-2-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 2
M4F741-E20-3-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 3
M4F741-E20-4-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 4
M4F741-E20-5-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 5
M4F741-E20-6-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 6
M4F741-E20-7-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 7
M4F741-E20-8-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 8
M4F741-E20-9-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 9
M4F741-E20-10-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos A-B-R connection | Port size: Rc3/4 | Stations: 10
M4F751-E20-2-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 2
M4F751-E20-3-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 3
M4F751-E20-4-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 4
M4F751-E20-5-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 5
M4F751-E20-6-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 6
M4F751-E20-7-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 7
M4F751-E20-8-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 8
M4F751-E20-9-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 9
M4F751-E20-10-CModel: 4F7 | Mounting: Manifold, common exhaust | Switching: 3-pos P-A-B connection | Port size: Rc3/4 | Stations: 10

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
